MIC-4S automatic polishing machine using advanced sample preparation capabilities, so sample preparation results is with consistency and reproducibility. This machine adopts the advanced microprocessor control system, which control sample preparation process. Grinding disc support bidirectional rotation, speed within a predetermined range can be adjusted. Pneumatic single point loading, it can support up to grinding and polishing 6pcs specimen simultaneously, also suitable for the single specimen sample preparation pressure, time setting is intuitive and convenient. MIC-4S is applicable to rough grinding, fine grinding, coarse polishing and polishing process as well as it is ideal equipment for enterprises, scientific research institutions and colleges laboratory.
Technical parameters
- Grinding disc diameter : φ250mm (φ203 optional)
- Grinding diac speed : 50-1000r/min(stepless) 150r/min,300r/min(two step speed)
- Grinding head speed : 5-100r/min
- Loading range : 5-60N
- Sample preparation time : 0-999s
- Sample diameter : φ30mm (can customize)
- Preparation sample quantity : 6PCS
- Gas source : 0.6-0.8MPa
- Lighting : LED
10.Input voltage : AC220V 50HZ
11.Input power : 1.1KW
12.Dimension : 730mmx710mmx635mm
13.Net weight : 98kgs
- Gross weight:122kgs
