S1205 Vibrating Microtome

S1205 Vibrating Microtome

This model is specially developed according to market demand,it introduce advanced technics from overseas.It is widely used in biological,teaching,scientific institute research etc.It is used to cut fresh or specific specimen from animals or plants,specimen can be cut immediately in no case of embedding,cooling progress.Therefore,specimen doesn’t broke at all,and cell keep very good and active.It provide good condition for immunocyto chemistry research and spinal&celebrum disorder’s neurobiology. This model is very good choice for fields in electron microscope,dissect, cyemology,physiology,biology,scientific research.

According to finding result from related college or scientific institute,10um is minimum section setting range when cutting brain or spinal cord specimen.And,30um when cutting fresh brain,heart,kidney specimen.

Technical Specifications:

1.  Speed of Specimen Sectioning: 0-1.3mm/s（adjustable）
2.  Vibrating range: 0～1mm
3.  Specimen table lifting range: 9mm
4.  Section thickness setting range: >10um
5.  Minimum setting value: 1um
6.  Angle of blade: 15degrees
7.  Working Voltage: AC220V    50Hz

AC110V    60Hz

8.  Power Draw:200VA
9.  Dimension:400x220x300mm

10  Net Weight:12kg

Package Info:

Dimensions:400×300×220mm,

Weight:20 kgs
