MIC TECH ZNCLBS serials Digital Mini Laboratory Magnetic Hotplate Stirrer

MIC TECH ZNCLBS serials Digital Mini Laboratory Magnetic Hotplate Stirrer

MIC TECH NEW LAB HOT PLATE MADE OF CERAMIC TOP PLATE, PID TEMPERATURE

CONTROL AND DIGITAL DISPLAY WHICH OFFERS EXCELLENT CHEMICAL

RESISTANCE.

  1. BLACK CERMIC COATED TOP PLATE PROVIDE EXCELLENT CHEMICAL

RESISTANCE, THERMAL-PROOF , AND CORROSSION RESISTANCE, BRIGHT WHITE

COLOR CERAMICS COATED PLATE ENHANCE SAMPLE VISIBILITY.

  1. FIXED SAFETY CIRCUIT OF 400 °C
  2. SMOOTH ACCELERATION OF STIRRING SPEED ENSURES NO SPILLAGE.
  3. DIGITAL DISPLAY FOR TEMPERATURE REDUCE , ADD AND SET
  4. HEAT ONLY, STIR ONLY OR HEAT AND STIR TOGETHER FUNCTION

E:ELECTRONIC SPEED CONTROL FOR CONSTANT SPEED EVEN DURING

CHANGE IN LOAD.

  1. HIGH MAGNETIC ADHESION
  2. VARIOUS SIZES OF THE TOP FLEXIBLE CHOICE.
ENQUIRY!
分类： , 标签：
描述

MIC TECH ZNCLBS serials Digital Mini Laboratory Magnetic Hotplate Stirrer

MIC TECH NEW LAB HOT PLATE MADE OF CERAMIC TOP PLATE, PID TEMPERATURE

CONTROL AND DIGITAL DISPLAY WHICH OFFERS EXCELLENT CHEMICAL

RESISTANCE.

  1. BLACK CERMIC COATED TOP PLATE PROVIDE EXCELLENT CHEMICAL

RESISTANCE, THERMAL-PROOF , AND CORROSSION RESISTANCE, BRIGHT WHITE

COLOR CERAMICS COATED PLATE ENHANCE SAMPLE VISIBILITY.

  1. FIXED SAFETY CIRCUIT OF 400 °C
  2. SMOOTH ACCELERATION OF STIRRING SPEED ENSURES NO SPILLAGE.
  3. DIGITAL DISPLAY FOR TEMPERATURE REDUCE , ADD AND SET
  4. HEAT ONLY, STIR ONLY OR HEAT AND STIR TOGETHER FUNCTION

E:ELECTRONIC SPEED CONTROL FOR CONSTANT SPEED EVEN DURING

CHANGE IN LOAD.

  1. HIGH MAGNETIC ADHESION
  2. VARIOUS SIZES OF THE TOP FLEXIBLE CHOICE.
Model ZNCLBS1140 ZNCLBS1180 ZNCLBS1230 ZNCLBS1280
Top Plate Dimension (mm) 140X 140

(5.51×5.51inch)

 180 X 180

(7.09×7.09inch)

 230 X 230

(9.05×9.05inch)

 280X 280

(11.02×11.02inch)
Heating Temperature for machine (°C ) Ambient to 400°C
Temperature  Control PID  auto control
Temperature max to top plate 325°C
Top Material black Ceramic -round plate
Temperature Display  (°C ) Digital display +/- 1
Thermocouple probe/sensor type PT100, with inner and outer thermocouple

Stir Speed 100-1800rpm
Stir Display Digital display
Permissible Ambient Temperature Ambient Temperature to 40°C
Voltage 160-240v, or 110-130v
Heating Power(w) 450 550 750 1000
Motor Power supply 40W, DC20V
Machine power supply 500 600 800 1100
Stirring flask Capacity for water 50- 2000ml 50- 5000ml 50-10000ml 50-15000ml
Overall Dimensions (mm)

( L × W × H )

 295 ×190 × 100 391× 245 ×120 445 ×353× 283 495× 382× 315
Packing Dimension (mm) 350 × 250 ×150 440× 290 ×170 500 × 400 × 350 550 × 420 × 370
Weight (kg) 3.5kgs 5.1kgs 6.9kgs 8.2kgs
Shell material Time molding waterproof and dust proof shell with anti-static paint

Standard Outfits

其他信息
microscope function

Infinite, Compound, Dark filed, Polarizing, PH, fluorescent
用户评价 (0)

评价

目前还没有评价

成为第一个“MIC TECH ZNCLBS serials Digital Mini Laboratory Magnetic Hotplate Stirrer” 的评价者

您的电子邮箱地址不会被公开。 必填项已用 * 标注

Shipping & Delivery

EX-WORK price

ALL PRICE MIC TECH QUOTED IS EX-WORK PRICE.

OTHER PRICE INCLUDING SHIPPING WILL BE QUOTED UPON REQUEST.

FAS CPT CIP FCA FOB CFR CIF DPT DIP DDP

  • ALL TERMS OF SHIPPING IS NEGOTIABLE WITH MIC TECH
  • ALL SHIPPING METHODS IS JUST ON YOUR REQUEST
  • YOUR SATISFACTION IS OUR GOAL

相关产品

Close

MIC-Q2016 rotary microtome

MIC-Q2016 rotary microtome It is our latest model that integrates the advantages of precision, stability and simplification which manual microtome entails. It is one of best model for histology and pathology preparation.
阅读更多
ENQUIRY!
Quick view
Close

MIC-Q1508III microtome with Computer Controlled Fast Freezing and Paraffin dual use
