ZNCL-DS Magnetic Hotplate Stirrer

ZNCLDL Magnetic Hotplate Stirrer

Top Material: Superfine Ceramics

Temperature Range: ambient to 400 degree, digital display , +/- 1 accuracy , PID control

Stir speed:0- 2500rpm , digital display ,+/- 1 rpm

Timer: 0~ 9999min

Heating and Stir Volume: 50ml – 15000ml

ENQUIRY!
分类： , 标签：
描述

Top Material: Superfine Ceramics

Temperature Range: ambient to 400 degree, digital display , +/- 1 accuracy , PID control

Stir speed:0- 2500rpm , digital display ,+/- 1 rpm

Timer: 0~ 9999min

Heating and Stir Volume: 50ml – 15000ml

Specification

Item Specification
Model ZNCLDL2140 ZNCLDL2180 ZNCLDL2230 ZNCLDL2280
Top Plate material white Ceramics
Stir Range 0~2000rpm
Stir Speed Accuracy ±1 rpm
Top Ceramic Dimension for each position 140 × 140 180 × 180 230 × 230 280 × 280
Working Time Continue
Position 2
Stir Speed Display Digital Display
Temperature Range for each position ambient to 400degree
Temperature  Accuracy ±1 degree
Temperature Control PID
Voltage 160-240V, 110-120V
Temperature Display Digital display
 Outer Thermo to measure and control the liquid temperature value together with the front panel
Inner Thermo . control and Measure the hotplate stirrer temperature
Motor Power for each position 8W, DC14V 8W, DC14V 40W, DC20V 40W, DC20V
Product power for each position 260 410 600 750
Stir Capacity for each position 50ml-1000ml 2000 50ml-10l 50ml-15l
Shell material Superfine metal
net weight (KG) 7 10 14 18
