DZXQ-1 automatic multi head inlay machine
DZXQ-1 automatic multi head inlay machine
Inlay is a very important link in the preparation of metallographic samples, especially for some small samples that are not easy to handle, samples with irregular shape that need to protect the edges or samples that need to be polished automatically, the inlay of samples is an essential process. DZXQ-1 automatic multi head inlay machine is an advanced hydraulic water-cooled automatic sample inlay equipment. The inlay process is controlled by a single-chip microcomputer program. It realizes the one key operation of the inlay process, such as heating, pressurization, pressure maintaining, cooling, pressure relief, and so on. It does not need operators to be on duty. It automatically completes the sample inlay and has the sound and light alarm function.
LZXQ-2 automatic metallographic sample inlaying machine
For the analysis of metallographic and petrographic samples, mosaic is the first process of sample preparation, especially for some small samples that are not easy to handle, samples with irregular shapes, or samples that need to be automatically ground and polished, mosaic before sample preparation is an important process.
LZXQ-2S automatic mosaic machine
LZXQ-2S automatic metallographic sample inlaying machine is a process before sample inlaying and polishing. It is used to inlay tiny or irregular metallographic and petrographic samples that are not easy to handle. After inlaying, it is convenient to grind and polish the sample and to observe the structure of the material under the metallographic microscope. The machine can automatically heat and pressurize. After pressing and forming, the machine will automatically stop to relieve pressure, and then press the button to automatically press the sample to automatically come up, that is, the cargo. Note: it is mainly used for thermosetting materials (such as Dianyu powder and bakelite powder). The temperature has been adjusted and automatically.
LZXQ-3 mosaic machine
The automatic metallographic and petrographic sample inlaying machine is a process before sample inlaying and polishing. It inlays tiny or irregular metallographic and petrographic samples that are not easy to handle. After inlaying, it is convenient to grind and polish the sample and to observe the structure of the material under the metallographic microscope. The machine can automatically heat and pressurize. After pressing and forming, the machine will automatically stop to relieve pressure, and then press the button to automatically press the sample to automatically come up, that is, the cargo. Note: it is mainly used for thermosetting materials (such as Dianyu powder and bakelite powder). The temperature has been adjusted and automatically
LZXQ-5 mosaic machine
LZXQ-5 sample inlaying machine is used to inlay those samples with inappropriate shape or size to meet the subsequent sample preparation steps and obtain the required detection plane; Or to protect edges or prevent surface defects caused by the preparation process. In modern metallographic laboratory, the widely used semi-automatic or automatic grinding / polishing machine has specification requirements for sample size. In order to meet this requirement, the sample must be inlaid. Therefore, the inlay machine has become one of the important equipment in metallographic laboratory.
LZXQ-5Q mosaic machine
LZXQ-5Q intelligent automatic metallographic inlay (pneumatic) inlay machine is an advanced hydraulic pneumatic water-cooled automatic sample inlay equipment. The whole process of inlay is controlled by the program, which realizes the one key operation of the inlay process such as heating, pressurization, load maintaining, cooling, unloading and sampling, and automatically completes the sample inlay without the operator on duty. Suitable for thermal inlay of all materials (thermosetting and thermoplastic); Program controlled intelligent operation (temperature, time, cooling, etc.) and suitable sample preparation specifications can be selected according to the actual situation You can also choose the model of replaceable steel mold sleeve.
MIC-ZXQ-5O mounting machine for metallographic specimen
Application
The sample inlaying machine can inlay improper samples in shape or size to meet the following sampling steps, to obtain required inspection surface, or to protect edges or surface defects caused in the course of sample preparation. In modern metallographic labs, semi-automatic or automatic grinding/polishing machines have a certain requirement in sample size, so the samples must be inlayed. The sample inlaying machine is an indispensable equipment in the metallographic labs.
The machine is an automatic metallographic sample inlaying machine with cooling function, applicable to thermal inlaying of all materials (thermoset and thermoplasticity). Set inlaying parameters such as heating temperature, heat holding time, acting force, etc., put sample and inlaying materials, close the gland, press down the button, and then the machine can inlay automatically without a watchman. The machines may change four kinds of dies at will according to various requirements of samples, and also can press two samples simultaneously.
MO-1 Metallographic specimen mounting press
MIC-MO-1 Metallographic specimen mounting press is suitable for the thermo-hardening plastic pressing of the small metallographic specimen which is not idiomorphic or hard to take. After forming, it will be very easy to process the grinding, polishing of the specimen and it is also convenient to process measuring of metallographic structure under metallographic microscope. The machine may work stable under the following working condition:
The temperature of surrounding medium can not be less than 10 °C and more than 40 °C
The relative humidity of air should be no more than 85% (20 °C)
The voltage fluctuation should be no more than 15%
There should be no obvious vibration source around
There should be no current conducting dust, explosive and corrosive air.
MO-5 Metallographic specimen mounting press
MIC-MO-5 automatic metallographic specimen mounting press is a kind of full automatic mounting press, equipped with in-out water cooling system. It is suitable for the heat mounting (thermo hardening & thermoplastic) for all kinds of materials. After the parameters such as heating temperature, heat preserving time and applied force etc. are set up, put the specimen and mounting material into the machine, close the cover and press the start button, then the machine will finish the job automatically. It is not necessary for the operator to be on duty. According to different requirements of the material, there are four kinds of moulds that can be chosen to meet the demands at will. Also it is available to prepare two pieces of specimens at the same time, the capacity is doubled.
MO-6 Metallographic specimen mounting press
MIC-MO-6 is a new Touch screen type Automatic Metallographic specimen mounting press, all working procedures can be done automatically. After the parameters such as heating temperature, heat preserving time and applied force etc. are set up, put the specimen and mounting material into the machine, close the cover and press the start button, then the machine will finish the job automatically. It is not necessary for the operator to be on duty. According to different requirements of the material, there are four kinds of moulds that can be chosen to meet the demands at will. Also it is available to prepare two pieces of specimens at the same time, the capacity is doubled.
