DY-1 Inverted Biological Microscope
In the CCIS infinity chromatic aberration revise system, process longer working distance. making better contrast and definition.
With human Engineering design, operating easily. The rigidity and shock-resistant capability is stable.
Adjusting center of phase slider fast and easily. Using center able phase annulus to minute adjusts for professional phase contrast result.
Using low-positioned coaxial mechanical moving ruler, you can control more comfortable. Cross travel 120x80mm. assembling different type of stages.
Total Magnification: 40X-1000X
DY-2 Inverted Biological Microscope
In the CCIS infinity chromatic aberration revise system, process longer working distance. making better contrast and definition.
With human Engineering design, operating easily. The rigidity and shock-resistant capability is stable.
Adjusting center of phase slider fast and easily. Using center able phase annulus to minute adjusts for professional phase contrast result.
Using low-positioned coaxial mechanical moving ruler, you can control more comfortable. Cross travel 120x78mm. assembling different type of stages.
Total Magnification: 40X-1000X
J-Y1 Inverted Biological Microscope
Model J-Y1 series Inverted Biological Microscope with its excellent optical capability ,wide application, firm body frame and skillful figure design, meet the demands of biology, microbiology, histology immunology and etc.
This inverted biological microscope provides excellent functions .High resolution and contrast long working distance objectives provide high quality image. High contrast Phase contrast objectives make the figure and configuration of the cells more clear .The long working distance condenser can contain higher vessels or samples.
The stable & reliable “T” type base, streamline figure design, simple and convenient operating system makes your work easy and relax.
L-I1 Inverted Biological Microscope
L-I1 Inverted microscope is equipped with wide field eyepieces, long working distance plan achromatic objectives, long working distance condenser and phase contrast unit. It can be observed transparent and unfinished living specimen in culture bottle or culture utensil. It is the ideal instrument suitable for research of living specimen structure, liquid, deposits and so on. It also can be used in research institutes, universities, medical treatment, agriculture and animal husbandry etc.
6V20W halogen lamp, adjustable brightness
L-I2 Inverted Biological Microscope
L-2 inverted microscope is equipped with wide field eyepieces, long working distance plan achromatic objectives and very long working distance condenser and phase contrast unit. It can be observed transparent and unfinished living specimen in culture bottle or culture utensil. It is the ideal instrument suitable for research of living specimen structure, liquid, deposits and so on. It also can be used in research institutes, universities, medical treatment, agriculture and animal husbandry, etc.
Features
▲ Equipped with wide field eyepiece, long working distance plan achromatic objectives
▲ Equipped with phase contrast unit, include very long working distance condenser, phase contrast objective and centering telescope
▲ Coaxial coarse/fine focus system with tensional adjustable and up stop, minimum division of fine focusing: 2μm
▲ 6V30W halogen lamp with brightness control
Magnification: 100X--400X
Illumination system: 6V30W halogen lamp, adjustable brightness
L-S3 Inverted Biological Microscope
L-S3 model inverted biological microscope is equipped excellent UIS optical system including long working distance plan achromatic objective and wide field plan eyepieces. Compact and steady main frame body is embodiment for the shock resistance. The enable turning out or into condenser system is suited for observation in a high culture dish. The ideal ergonomic design is adopted in this unit and have easier operation and wider space. This is ideal optical instrument for micro observation in cell tissue and transmitted liquid tissue, even in dynamic observation in the culture dish tissue. It can be used in scientific research, universities, medical treatment, epidemic prevention, agriculture etc.
Magnification: 100X--400X illumination system: 6V30W halogen lamp, adjustable brightness
L-S3DIC Inverted Microscope
Transmitting interference phase contrast observation is suitable for those transparent or semi-transparent samples or tissues.
MIC TECH L-S3DIC model microscope is equipped with 10X,20X DIC phase contrast objectives. Under the orthogonal state of linearly polarized light, through the DIC Beam splitting prism, make the polarized light divided to 0 line and E light. And this two lights will have tiny optical path difference after passing the tissue samples.Then the 0 and E light combine together after DIC composite prism, at the same time make interference at the rear focal plane of the objective which makes interference image. Users get clearer image after analyzer lens which looks like 3D image.
L-S3L Inverted Cell Microscope
L-S3L model inverted biological microscope is equipped excellent UIS optical system including long working distance plan achromatic objective and wide field plan eyepieces. Compact and steady main frame body is embodiment for the shock resistance. The enable turning out or into condenser system is suited for observation in a high culture dish. The ideal ergonomic design is adopted in this unit and have easier operation and wider space. This is ideal optical instrument for micro observation in cell tissue and transmitted liquid tissue, even in dynamic observation in the culture dish tissue. It can be used in scientific research, universities, medical treatment, epidemic prevention, agriculture etc.
Magnification: 100X--400X illumination system: 9W LED lamp, adjustable brightness
L-S3M Modulation Contrast Microscope
MIC TECH L-S3M inverted polarizing modulation contrast microscope is a new type of multi-functional optical instrument. Modern design with convenient operation. The phase contrast device can be attached to the light path to perform transmitting phase contrast microscopic observation, such as phase contrast, modulation contrast and etc. This unit is suitable for the microscopic observation of cell, tissues and clear liquid tissues, and the dynamic microscopic observation of tissues cultured in a culture dish, and is applicable to scientific research institutions, colleges and universities, medical and health, inspection and quarantine agencies, agricultural, animal husbandry and dairy industries.
The principle of polarizing modulation contrast is that it can converts phase gradients into intensity variations, thereby making transparent specimens clear with vivid details. The PMC system is a cost-effective upgrade for 3D appearing image. As a feature which appears to cast a shadow may not necessarily have distinct physical geometry
Equipped with high quality modulation contrast plan objective 10X, 20X, 40X, and modulation contrast condenser. There are two mode modulation contrast, turntable type and puller type
L-S5 Inverted Biological Microscope
MIC TECH L-S5 inverted biological microscope
9WLED light
MIC TECH L-S5 inverted microscope is multi-functional microscope. It adopts excellent infinite optical system and provides extraordinary optical functions. It is designed with good shape, easy to operate. The long working distance condenser is very suitable for tissue observation in a tall culture dish. The illumination system is designed well for heating spreading and user’s safety. The phase contrast device can be attached to the light path to perform transmitting phase contrast microscopic observation. This unit is suitable for the microscopic observation of cell, tissues and clear liquid tissues, the dynamic microscopic observation of tissues cultured in a culture dish and is applicable to scientific research institutions, colleges and universities, medical and health, inspection and quarantine agencies. Agricultural, animal husbandry and dairy industries.
MIA-D1 Inverted Biological Microscope
In the CCIS infinity chromatic aberration revise system, process longer working distance. making better contrast and definition.
With human Engineering design, operating easily. The rigidity and shock-resistant capability is stable.
Adjusting center of phase slider fast and easily. Using center able phase annulus to minute adjusts for professional phase contrast result.
Using low-positioned coaxial mechanical moving ruler, you can control more comfortable. Cross travel 120x80mm. assembling different type of stages.
Total Magnification: 40X-900X
