An unprecedented high-speed focusing experience
MIC-AF offers both continuous and single-shot autofocus modes. It also supports mouse wheel control for fine-tuning. Data transfer up to 60 frames per second enables users to get clear images with ease.
Professional digital image measurement system
MIC-AF provides extremely powerful measurement functionalities including, freehand line, rectangle, polygon, circle, bicircle, angle, point-line distance and much more. Three different length units of millimeter, centimeter, and micrometer are provided to meet various measurement requirements in different applications.
Compatible with Mosaic V2.1 Computational Imaging Software
Fast, efficient and worry-free is the core design concept of Mosaic V2.1 software. It adopts a new image “shooting-processing-measurement-reporting” function, modular design, and integrates various intelligent image processing algorithms from MIC TECH. It is dedicated to providing users with more simple operation modes and improve work efficiency in all circumstances.
Real-time image stitching
It can generate large-sized mosaic images in a few seconds while moving the stage, which is light, smooth and worry free!
The continuation of the MIC-AF
Perfect color reproduction
MIC TECH’S color processing is capable of a new level of precision, matches the monitor image to the eyepiece view, produces extremely-high color definition.
Fastest USB2.0 camera with 30 fps
With 30fps data transfer at an uncompressed resolution of 1920X1080, MIC-AF sets a precedent. Make it one of the fastest USB2.0 camera in the world.
Tailored 1080P HD screen
In order to let users better feel the excellent quality of the MIC-AF cameras, we specially customized a 1080P high definition display screen, which perfectly matches the performance of MIC-AF camera.
Note: Retina Screen is an optional accessory that users can choose to use.
| Product Model | MIC-AF |
| Sensor Type | CMOS |
| Sensor size | 1/2.8″ |
| Preview Resolution | 2MP, 1920×1080 |
| Capture Resolution | 6MP, 3264×1836 |
| Frame | 60fps @HDMI, 35fps @USB2.0 |
| Capture | SD card(16G) |
| Video Recording | 30fps @SD Card, 30fps @PC |
| Exposure Mode | Auto/Manual |
| Exposure Time | 2ms~10s |
| White Balance | Auto/Manual |
| Setting | White Balance,Exposure Time,
Noise,Reduction,Gain,Gamma,WDR |
| Built-in Software | Cloud 1.0 Ver |
| PC software | Mosaic V2 |
| Data Interface | USB2.0,SD,HDMI |
| Optical interface | Windows 7/8/10(32/64bit), Mac |
| Optical Port | Standard C-Mount |
| Camera size | 90.7x78x70.8(mm) |
| Camera weight | 460g |
