MIC-CD510–3A Portable economic ophthalmology eye ophthalmic operating microscope
MIC TECH high performance microscope is the perfect combination of excellent optical quality and comfortable handling.
MIC TECH professional surgery microscope, you see a fashionable, smooth lines, beautiful shape with a sense of modern design of high-end microscope, and modern consulting room perfect fit.
Under the fashionable appearance is full of excellent optical quality, you have upgraded to a higher level of clinical treatment,bringing you a higher quality, more efficient work experience.
MIC TECH operating microscope allows users to easily adjust the focal length without changing the sitting position or opening and moving the lens. Easier operation to prevent prolonged strain of cervical and lumbar spine.
With outstanding light transmission, MIC TECH results in significantly reduced light exposure for your patients, leading to less stress on the eye.
APO-achromatic optics provide an exceptional view with high contrast and outstanding resolution.
German imported gas spring, the optimized force word structure enables you to move microscope any desired working Angle conveniently and precisely.
With the integration of electronics in the arm, the MIC TECH microscope is compact.
High quality imported silent medical mobile base casters, four wheels can be locked.
A modular solution to fit your needs
MIC TECH microscope systems offer brand new dimension in performance, flexibility and economy in diagnosis and surgery. MIC TECH microscope packs a high level of performance in a small package. Its compact design is tailored to optimize use of limited operating room space.
A highly efficient 20W LED illumination system with CRI 90 produces over 60,000 hours of bulb life with Xenon-level light intensity, providing a bright white light for precision work. Housed within the swivel arm, this compact illumination ensures a light, well-balanced microscope for both hospitals and clinics.
1080P full HD image quality, efficient image management during the operation. Integrate your digital workflow to facilitate case management and facilitate more intuitive patient communication
| Model | MIC-CD510-3A |
| Function | ophthalmology |
| Electrical data | |
| Power socket | 220v(+10%/-15%) 50HZ/110V(+10%/-15%) 60HZ |
| Power consumption | 40VA |
| Safety class | class I |
| microscope | |
| Magnification | manual 3-step changer, ratio 0.6，1.0，1.6 , total magnification 6,x 10x，16x ( F 200mm), |
| Focusing range | 50mm |
| Binocular tube | 45° tube |
| Eyepiece | 12.5x / 10x |
| Stereo base | 22mm |
| Objectives | F=200mm |
| Pupil distance | 55mm~75mm |
| Diopter adjustment | +6D ~ -6D |
| Light source | LED cold light |
| Built-in filter | Red free filter, small spot, Ocular protector |
| Light intensity adjustment | Using a drive knob on the optics carrier |
| Stands | |
| Max extension range | 1193mm |
| Base | 610 × 610 mm |
| Transportation height | 1476 mm |
| Balancing range | Min 4 kg to max 7.7 kg load on the optics carrier |
| Brake system | Fine adjustable mechanical brakes for all rotation axes with detachable brake |
| System weight | 68 kg |
| Stand options | Ceiling mount,Wall mount,Floor plate,Floor stand |
| Accessories | |
| Binocular tube | Selection of fixed and variable observation angle |
| CCD Camera system | Beam splitter, CCD adapter, CCD, Display |
| Mobile phone adapter | Compatible with all models |
| Integrated Video Adapter | SONY / CANON Camera |
| Video accessories | |
| CCD Camera system | Beam splitter, CCD adapter, CCD, Display |
| Mobile phone Adapter | Compatible with all models |
| Integrated Video Adapter | SONY / CANON Camera |
| Ambient conditions | |
| Use | +10°C to +40°C |
| 30% to 75% relative humidity | |
| 500 mbar to 1060 mbar atmospheric pressure | |
| Storage | –30°C to +70°C |
| 10% to 100% relative humidity | |
| 500 mbar to 1060 mbar atmospheric pressure | |
