MIC TECH professional surgery microscope, you see a fashionable, smooth lines, beautiful shape with a sense of modern design of high-end microscope, and modern consulting room perfect fit.
Under the fashionable appearance is full of excellent optical quality, you have upgraded to a higher level of clinical treatment,bringing you a higher quality, more efficient work experience.
MIC TECH operating microscope allows users to easily adjust the focal length without changing the sitting position or opening and moving the lens. Easier operation to prevent prolonged strain of cervical and lumbar spine.
Convenient positioning, Angle adjustment, comfortable feel.
LED lighting system, providing you with excellent lighting effect, Brightness control and filter selection, can meet your different treatment needs.
Eyepiece adopts 12.5/ 10x wide-angle eyepiece, which can provide large field of view and 3D stereoscopic imaging. Diopter +6- 6D diopter range, eye cup height adjustable, the operator of the glasses can be comfortable without the glasses to complete the work.
German imported gas spring, the optimized force word structure enables you to move microscope any desired working Angle
conveniently and precisely.
The main characteristics of MIC TECH operating microscope are compact design, excellent performance and simple operation. Maintaining a comfortable work position throughout your treatment can prevent back and shoulder strain, pain, and more serious spinal problems.
A modular solution to fit your needs
1080P full HD image quality, efficient image management during the operation. Integrate your digital workflow to facilitate case management and facilitate more intuitive patient communication.
Product Parameter
| Model | MIC-CD510-5A |
| Function | ENT |
| Electrical data | |
| Power socket | 220v(+10%/-15%) 50HZ/110V(+10%/-15%) 60HZ |
| Power consumption | 40VA |
| Safety class | class I |
| Microscope | |
| Tube | 90 degree binocular tube |
| Magnification | manual 3-step changer, ratio 0.6,1.0,1.6
total magnification 3.75x, 6.25x,12x ( F 250mm) 5 steps ,ratio 0.4,0.6,1,1.6,2.5 |
| Stereo base | 22mm |
| Objectives | F=250mm (200mm,300mm,350mm,400mm or 180mm-300mm adjustable objectives for optional) |
| Objective focusing | 15mm |
| Eyepiece | 12.5x/ 10x |
| Pupil distance | 55mm~75mm |
| Diopter adjustment | +6D ~ -6D |
| Field of view | 3 steps: 53mm,32mm,20mm
5 steps:55.6mm,37.1mm,22.2mm,13.9mm,8.9mm |
| Reset functions | yes |
| Light source | LED cold light with life time >80000 hours, brightness >60000 lux , CRI>90 |
| filter | OG530, Red free filter, small spot |
| Balance arm | 120° Balance arm |
| Automatic switching device | Built-in arm |
| Light intensity adjustment | Using a drive knob on the optics carrier |
| Stands | |
| Max extension range | 1193mm |
| Base | 610 × 610 mm |
| Transportation height | 1476 mm |
| Balancing range | Min 4 kg to max 7.7 kg load on the optics carrier |
| Brake system | Fine adjustable mechanical brakes for all rotation axes with detachable brake |
| System weight | 68 kg |
| Stand options | Ceiling mount,Wall mount,Floor plate,Floor stand |
| Accessories | |
| Binocular tube | 90° fixed or 0-200° |
| Knobs | Serializable |
| Tube | 90° binocular tube ,0-200° tube |
| Video adapter | Mobile phone adapter, beam splitter, CCD adapter, CCD, SLR digital camera adapter, MIC TECH adapter |
| Ambient conditions | |
| Use | +10°C to +40°C |
| 30% to 75% relative humidity | |
| 500 mbar to 1060 mbar atmospheric pressure | |
| Storage | –30°C to +70°C |
| 10% to 100% relative humidity | |
| 500 mbar to 1060 mbar atmospheric pressure | |
| Limitations on use | |
| The MIC TECH surgical microscope may be used in enclosed rooms and on flat surfaces with max. 0.3° unevenness; or at stable walls or ceilings that fulfill Leica Micro-systems’ specifications | |
