MIC TECH microscope configured with XYZ motorized movement operated through a comfortable foot /Handle control, a very effective co-axial illumination and 50W halogen light source makes it ideal for Neuro surgeries.
Doctor-patient communication is easier
To address digital documentation needs, a host of digital SLR, video camera, and CCD adapters are made available with the Proline in addition to MIC TECH’S proprietary IVU multi-functional imaging solution.
More comfortable operation
Tiltable binocular tubes available, which can incline more than 60° depending on the posture and physique of the operating surgeon.
Movable range: 30° (straight) to 90° (inclined)
1080P full hd image quality, efficient image management during the operation. Integrate your digital workflow to facilitate case management and facilitate more intuitive patient communication.
Product Parameter
| Model | MIC-CD5C motor-driven surgery microscope |
| Function | Neurosurgery |
| Surgical microscope | |
| Magnification | motorized zoom system, 1:6 zoom ratio, magnification 3x~16x |
| Focusing range | 50mm |
| Binocular tube | 30°~90° tiltable tube ，(0° ~200° optional) |
| Eyepiece | 12.5x / 10x |
| Objective lens | F 300mm(175mm, 250mm, 350mm optional) |
| pupil distance | 55mm~75mm |
| diopter adjustment | +6D ~ -6D |
| Feild of veiw | Φ74~Φ12mm |
| X-Y translator | Motorized by foot switch or handle controller, ±30mm |
| Assistant tube | 360° Rotating assistant tube |
| Reset functions | YES |
| Illumination | |
| System | Coaxial illumination |
| Light source | Halogen lamp |
| Light intensity adjustment | Continuous brightness adjustment 0-100000lux |
| Fiber optic illumination | Dual fiber |
| Field of illumination | Φ50mm |
| Fliter | Red free filter, small spot |
| Arm & Base | |
| Mount | Floor stand |
| Maximum arm extension |
1200mm |
| Height from objective to floor | 800mm |
| Base size | 800*800mm |
| Brake system | Four-wheel brake |
| Foot switch/Handle controller | Waterproof, 8 function steps |
| Others | |
| Weight | 169KG |
| Power socket | 220v(+10%/-15%) 50HZ/110V(+10%/-15%) 60HZ |
| Power consumption | 300VA |
| Safety class | class I |
| Accessories | |
| CCD Camera system | Beam splitter, CCD adapter, CCD, Display |
| XENON LAMP | 150000lux |
| Integrated Video Adapter | SONY / CANON Camera |
| Ambient conditions | |
| Use | +10°C to +40°C |
| 30% to 75% relative humidity | |
| 500 mbar to 1060 mbar atmospheric pressure | |
| Storage | –30°C to +70°C |
| 10% to 100% relative humidity | |
| 500 mbar to 1060 mbar atmospheric pressure | |
| Limitations on use | |
| The MIC TECH MIC-CD5 surgical microscope may be used in enclosed rooms and on flat surfaces with max. 0.3° unevenness; or at stable walls or ceilings that fulfill Leica Microsystems’ specifications (see installation manual) |
|
