Specification
Eyepieces magnification 12.5x, pupil distance adjustable range 55mm~75mm, diopter adjustment range +6D ~ -6D. Focus of second object lens 180mm.
Binocular tube 30°~90°variable angle binocular tube, add new pupil distance adjustment
Magnification 6:1 zoom, motorized, magnification 5.1x~30.6x; field of view Φ45~Φ7.5mm
Coaxial assistant’s binocular tube manual 3-step changer, total magnification 6.4x,10.8x,17.3x; field of view Φ31mm,Φ19mm,Φ12mm
Coaxial illumination illumination diameter of light spot Φ50mm, illumination intensity 100000lux
Oblique illumination illumination range 50mm,illumination intensity 25000lx
Objectives f 200mm (175mm, 250mm etc )
Focusing motorized, range +/-25mm, speed 33s/whole distance
X-Y translator move in X-Y direction motorised, range +/-30mm
Maximum length of arm 1200mm
Stand swing angle of the carrier arm 0 ~300°,height from objective to floor 800mm<H<1250mm
Foot switch waterproof, 8 function steps
Weight 164kg
