| MIC-DM specification | |||||
| No Z axis
measurement |
Model | DM-200 | DM-300 | ||
| With Z axis
measurement |
Model | DM-200H | DM-300H | ||
| Continuous zoom lens | Zoom lens | 0.75-5.25 | 1.5-10.5 | 3.75-26.25 | 7.5*52.5 |
| Total mage（17”LCD） | 40-278 | 79.5-556.5 | 199-1391 | 397.5-2782.5 | |
| Field of view | 8.5-1.2 | 4.27-0.61 | 1.71-0.24 | 0.85-0.12 | |
| Focusing | max sample height | 150mm | 200mm | ||
| focus | Coaxial focus（coarse：40mm/c、fine focus：0.02mm/c） | ||||
| Illumination | transmitting | telecentric illumination, step-less brightness adjustable, 5W LED light | |||
| reflecting | Kholer illumination, iris aperture adjustable,
step-less brightness adjustable, 5W LED light |
||||
| oblique | LED ring light/cold fiber light | ||||
| Stage | measure range | 100*100mm | 150*100mm | ||
| metal stage size | 285*250mm | 300*250mm | |||
| glass size | 170*145mm | 204*145mm | |||
| Fast delivery device | Standard specification | ||||
| Digital calculator | Min read | Customer can choose 1/0.5/0.1μm | |||
| Function | Zero setting,middling,reversing, Metric imperial system switch,
RS232 output |
||||
| Accuracy | （3+0.02L）μm L is measurement length | ||||
| Power | 45W、85～240VAC 50/60HZ | ||||
| Main body | Dimension
(W*D*H)mm |
605*640*710 | 720*700*720 | ||
| Weight | 70KG | 105KG | |||
