L3CMOS Data sheet C:Color; M:Monochrome;
| Order Code | Sensor & Size(mm) | Pixel(μm) | G Sensitivity | FPS/Resolution | Binning | Exposure |
| Dynamic Range | ||||||
| SN Ratio | ||||||
| L3CMOS14000
KPALP114000A |
14M/MT9F002(C)
1/2.3“(6.451×4.603) |
1.4×1.4 | 0.724v/lux-sec
65.3dB 35.5dB |
6.2@4096×328620.8
@2048×164453.3 @1024×822 |
1×1,2×2,4×4 | 0.1ms~2000ms |
| L3CMOS10000
KPALP110000A |
10M/MT9J003(C)
1/2.3“(6.44×4.616) |
1.67×1.67 | 0.31v/lux-sec
65.2dB 34dB |
7.2@3584×274624.5
@1792×1372 |
1×1,2×2,4×4 | 0.1ms~2000ms |
| L3CMOS08500
KPALP108500A |
8.5M/Special(C)
1/2.4“(5.557×4.255) |
1.67×1.67 | 0.31v/lux-sec
65.2dB 34dB |
8.3@3328×254826.2
@1664×1272 |
1×1,2×2,4×4 | 0.1ms~2000ms |
| L3CMOS05100
KPALP105100A |
5.1M/MT9P006(C)
1/2.5“(5.7×4.28) |
2.2×2.2 | 1.76v/lux-sec
67.74dB 38.5dB |
14.2@2560×192238.3
@1280×960101.2@640×480 |
1×1,2×2,4×4 | 0.05ms~2000ms |
| L3CMOS03100
KPALP103100A |
3.1M/AR0330(C)
1/3“ (4.505×3.37) |
2.2×2.2 | 1.9v/lux-sec
100dB 39dB |
27.3@2048×153453.3
@1024×770 |
1×1, 2×2 | 0.1ms~2000ms |
| Other Specification for L3CMOS Camera | |
| Spectral Range | 380-650nm (with IR-cut Filter) |
| White Balance | ROI White Balance/ Manual Temp Tint Adjustment/NA for Monochromatic Sensor |
| Color Technique | Ultra-FineTM Color Engine/NA for Monochromatic Sensor |
| Capture/Control API | Native C/C++, C#/VB.NET, Direct Show, Twain and Labview |
| Recording System | Still Picture and Movie |
| Cooling System* | Natural with High Performance Cooling Structure |
| Operating Environment | |
| Operating Temperature(in Centidegree) | -10~50 |
| Storage Temperature(in Centidegree) | -20~ 60 |
| Operating Humidity | 30~80%RH |
| Storage Humidity | 10~60%RH |
| Power Supply | DC 5V over PC USB Port |
| Software Environment | |
| Operating System | Microsoft® Windows®XP/Vista /7 / 8 /10 (32 & 64 bit) OSx (MacOS X) Linux |
| PC Requirements | CPU: Equal to Intel Core2 2.8GHz or Higher |
| Memory:2GB or More | |
| USB Port:USB3.0 High-speed Port | |
| Display:17” or Larger CD-ROM | |
