| Item | Specification | MIC-
NE910 |
|
| Optical System | NIS Infinite Optical System | ● | |
| Eyepiece | SW10X/25 SW10X/22 EW12.5X/17.5 WF15X/16
WF20X/12 |
● | |
| Viewing Head | Seidentopf Binocular Head Inclined at 30°, Interpupillary 47-78mm | ● | |
| Seidentopf Triocular Head Inclined at 30°(100/0, 20/80,0/100), Interpupillary 47-78mm | ○ | ||
| Erog Tilting trinocular head adjustable 0-35°(100/0, 20/80,0/100), Interpupillary 47-78mm | ○ | ||
| LCD screen | ○ | ||
| Nosepiece | Auto Sextuple Nosepiece with code
Manual sextuple nosepiece |
● | |
| Objective | N-PLAN objective | 4X,10X,20X,40X,60X,100X | ● |
| N-PLAN Phase contrast objective | PH 4X,10X,20X,40X,60X,100X | ○ | |
| Condenser | Swing out condenser N.A 0.9/0.25 | ● | |
| Turret phase contrast condenser | ○ | ||
| Dark field condenser dry | ○ | ||
| Dark field condenser oil | ○ | ||
| Stage | Double layer mechanical stage 190x152mm, moving range 78x32mm right or left hand , 1mm/grid, precision 0.1mm ( with sapphire crystal glasses surface as optional) | ● | |
| Auto stage | High precision auto stage XY, moving range X axis 125mm, Y axis 75mm, repetition ±1.5um, maximum speed 20mm/s | ○ | |
| Focusing | Coaxial coarse and fine adjustment, fine division 1um, moving range 35mm | ● | |
| Illumination | 12V100W halogen lamp 3W LED lamp | ● | |
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological advances, we have reserved
the right to make design modification and changes without notice.
