MIC-TS4A orthopedics, hand surgery, orthopedic surgery, obstetrics and gynecology, surgical microsurgery surgical operating microscope

MIC-TS4A orthopedics, hand surgery, orthopedic surgery, obstetrics and gynecology, surgical microsurgery surgical operating microscope.

The MIC-TS4A surgical microscope is a good performance, can be widely used in medical optical instruments for micro-surgery and animal experiments. The instrument is mainly applied to orthopedics, hand surgery, orthopedic surgery, obstetrics and gynecology, surgical microsurgery the micro vascular and easy to fit, but also can be used for microsurgery animal experiments.

Feature：

1: Imaging clear, strong sense of stereological

2: two doctors observed the same optical path

3: the wide field of vision, cold light source coaxial within lighting

4: lightweight, flexible, easy to operate

Technical parameters:

1.Double binocular 180 ° postural same optical path, the same magnification, the same orientation

2 eyepiece: 12.5x/22B, interpupillary distance 44-80mm

3.Magnification: 8x, 10x

4.bracket Lifting range: spring arm    adjustment range 300 ~ 500mm,

Electric micro lifting range of 40 ~ 50mm

5.Electric micro lifting speed 2.5mm / s

6.direction adjustment range: ± 180 ° level of around ± 90 °

7.maximum radius of gyration of the wishbone 800mm

8.spot center maximum illumination> 30000 ~ 60000Lx

9.8V 50W coaxial illumination of cold light source

10.Power supply voltage: 220V ± 10% 50Hz

11.Optional dual lamp conversion and xenon lamp lighting conveniently applicable

The main performance indicators：

1. Mechanical properties:

1) Bracket Lifting range, spring arm adjustment range of 250 mm electric micro lifting range of 50 mm.

2) Electric micro vertical speed of 2.5 mm / sec.

3) The direction of adjustment range: Horizontal ± 180 ° ± 90 °.

4) Maximum radius of gyration of the wishbone: 800 mm.

2. Electrical performance:

1) The maximum illumination of the spot center: not less than 15000LK

2) Bromine tungsten lamp: 8V 50W

3) Power supply voltage: 220V ± 1% 50HZ
