MIC-TS4C ophthalmic surgical operating microscope
Product Describe
- Application
MIC-TS4C microscope is a new-developed portable and popular instrument produced on the basis of 30 years development of the microscope technology of MIC TECH. It can be used widely in the field of ophthalmic operations and ophthalmic experiments for medical hospitals enterprise and towns. It is an essential medical instrument of ophthalmic micro-technology with excellent quality and a reasonable price.
- Features
1) Widely visual angel, clear imageries，binocular head with assistant head 90° inclined, optical angle is 12°between the assitant lens and major lens.
Eyepiece 12.5X/22mm, interpupillary distance 54-75mm, working distance 200mm
Major lens mag 10x, assitant lens 4X
Major lens field of view 27.5mm
2) Coaxial cold light source bright and clear in depth.
3) Third-mirror provided for two persons to operate together
4) Slight adjusting by foot light and handy convenient for operation and carrying about.
3 MAJOR TECHNICAL INDEX
1) Mechanical performance:
- A) Stand up-down range: Spring arm adjustment range:250mm; motorized up-down range:50mm
- B) Motorized up-down speed: 2.5mm/s
- C) Direction Adjusting RangeLevel:±180ºLeft and Right: ±90º
- D) Longest Turning Radius of Cross-Arm:800mm
2) Electric Features
- A) Maximum illumination of light source. Not Lessthan 15000LX
- B)Bromine and Tungsten Lamp:8V 50W
- C) Voltage Of Power:220±10% 50Hz
| Working distance | 193 mm |
| Coaxial illumination | >=15000Lx |
| Magnification | Assistant lens 4x, 10x |
| Diameter of Field view | 27.5mm, assistant lens 52mm |
