MIC-2000i serials biological microscope
Back to products
Next product
PH20w digital thermostat microscope

PH20 biological microscope

The PH20 series biological microscopes, the biological microscopes recommended by the new curriculum standards, are very suitable for observing biological slices and specimens in elementary and middle schools. It can also be used for routine inspection and analysis of biology and pathology in health inspection departments.

Product Features:

  • Monocular observation tube

45° inclined, 360° rotatable

  • Wild-field eyepiece

WF16X/11MM, WF10X/16MM

  • Achromatic objective

4X, 10X, 40X(Spring)

  • Mobile round stage, slice clamp

Diameter: 90, circular movement range: 6mm (with white frosted glass)

  • Coarse and fine focusing on different axes

Coarse adjustment stroke: 10mm, fine adjustment accuracy: 1.8mm

  • Lighting system

Plano-concave mirror, 40mm

High brightness LED, cold light source, rechargeable, adjustable brightness

  • Handle

Built-in handle, easy to take and move

  • Power supply

External switching power supply (adapter), AC95V-250V

ENQUIRY!
分类： , , 标签： , ,
描述

PH20 Series Biological Microscope Main Parameters

Model Number PH20-1A31L-A PH21-1600X PH23
Total magnification 40X-640X 100X-1600X 40X-1000X
Observation tube Monocular tube,45°inclined,360° rotatable Inclined binocular tube
Eyepiece Wide field,WF10X/Φ18mm,Huygens H16X/Φ11mm Wide field, WF10X
Objective 195

Achromatic

 4X, 10X, 40X(Spring) 10X, 40X(Spring),

100X(Spring, Oil)

 4X, 10X, 40X(Spring),100X(Spring, Oil)
Nosepiece Three holes, inward Four Holes Nosepiece,outward
Stage Round stage with slice holder, diameter: Φ90mm,circumferential movement range:6mm (with white ground glass) Double-layer mechanical stage,aluminum alloy casting,moving range:60mmX30mm
Focusing mechanism Different coarse and fine adjustment, coarse focusing range 10mm,

fine focusing graduation: 1.8mm
Condenser / High transmission condenser
Illumination High brightness LED, cold light source,rechargeable, adjustable brightness LED cold light source lighting, 1W LED,400mAH rechargeable battery, with charging indicator, stepless adjustable light source brightness
Power cord plug 220V/50HZ, Chinese standard
Design for client
Package Foam+carton Nylon bag Foam+carton
其他信息
microscope function

finite, Compound
