MODEL XQ-2B METALLOGRAPHIC SPECIMEN MOUNTING PRESS
Model XQ-2B Metallographic specimen mounting press is suitable for the thermo-hardening plastic pressing of the small metallographic specimen which is not idiomorphic or hard to take. After forming, it will be very easy to process the grinding, polishing of the specimen and it is also convenient to process measuring of metallographic structure under metallographic microscope, or hardness testing. This machine adopts digital display temperature controller to control the temperature, and uses timer to control the sample preparing time. After sample preparation is finished, it will cut off power supply automatically. It is the ideal sample preparing equipment to be used in factories, researching institutes and college laboratories.
Technical parameters
| Model | XQ-2B |
| Specimen mould diameter | Φ22mm, Φ30mm, Φ45mm
(choose one diameter as standard configuration when purchasing) |
| Temperature controlling range | Room temperature ~ 190℃ |
| Time controlling range | 0~60 minute |
| Power | ≤800W |
| Power supply | AC220V, 50Hz, single-phase |
| Dimensions | 360mm*290mm*440mm |
| Net weight | 35kg |
