USB3.0 microscope camera
MIC-D40D USB3.0 microscope camera
MIC-D40D is equipped with a brand new 1.2 inch scientific CMOS sensor, which provide 80% quantum efficiency at 600nm. The 1.2 inch sensor size and 6.5X6.5um pixel size is more suitable for microscopy standard C-mount imaging.
When comparing to other existing scientific CMOS camera products, MIC-D40D has a hardware 2X2 binning function which make it superior sensitivity for low light imaging.
MIC-D40DC USB3.0 microscope camera
MIC-D40DC
By combining their legendary color processing technology with the capabilities of the latest generation SCMOS sensors, MIC TECH have created a paradigm shift in color camera performance. The launch of the MIC-D40DC, thanks to its sensitivity, perfect color reproduction and impressive noise minimization, results in a new capability which has formerly been unavailable in the field of scientific imaging.
High Sensitive color
Perfect 16bit color reproduction
Peltier cooled device
SCMOS Camera with True Color
MIC-D4BSI USB3.0 microscope camera
The new MIC-D4BSI achieves a paradigm shift on multiple core metrics such as sensitivity, speed and resolution. Not only does it have a 95% super-high quantum efficiency, but also achieves breakthroughs in key technologies that deliver a readout noise of less than one electron from a smaller 6.5um pixel size, that enables greater performance in, for example, ultra-high resolution microscopy.
95% @ 550nm, super-high quantum efficiency
<1.0e-@CMS, ultra-low readout noise
Built in signal enhancement algorithm
6.5μm size, higher image resolution
MIC-D95V2 USB3.0 microscope camera
MIC-D95V2 adopts MIC TECH’S new technology and performance standard. The smallest dimension among peers for scientific imaging makes it perfect for demanding compact space. The water-cooling method and CameraLink interface apply the camera for conditions requiring high stability.
Features
95% ultra-high quantum efficiency
2" Sensor area
11um x 11um pixel size
100Ke- full-well capacity
Air/Water cooling
USB3.0/CameraLink
MIC-E3 serials USB3.0 CMOS microscope camera
MIC-E3 serials USB3.0 CMOS microscope camera
E3CMOS adopt SONY Exmor CMOS sensor as the image-picking device and USB3.0 is used as the data transfer interface.
E3CMOS hardware resolutions range from 2.3M to 20M and come with the integrated CNC aluminum alloy compact housing.
E3CMOS comes with advanced video & image processing application system ; Providing Windows/Linux/ OSX multiple platforms SDK; Native C/C++, C#/VB.NET,Direct Show, Twain Control API;
TheE3CMOS can be widely used in bright field light environment and microscope image capture and analysis with higher frame rate.
