3.2inch large area array, 9μmx9μm big pixel
The large imaging area is not only a standard for Astronomy imaging, but an ideal solution for high-energy physics applications, such as optical field measurement.
70Ke- high full-well capacity, 0.05e-/p/s ultra-low dark current
The high full-well capacity and excellent cooling performance with ultra-low dark current allows MIC-D4040 to acquire the brilliant image quality with low noise even under long exposure times.
74%@600nm high quantum efficiency, fast frame rate output
With the decent sensitivity and high frame rate, MIC-D4040 is able to get the same data volume in shorter time compared with traditional CCD camera.
| Model | MIC-D4040 |
| Sensor size | 3.2 inch |
| Sensor model | FSI SCMOS |
| Color/monochrome | Monochrome |
| Quantum efficiency | 74%@600nm |
| Effective no. of pixels | 4096(H) x4096(V) |
| Pixel size | 9 μ m x 9 μ m |
| Effective area | 36 . 9mm x 36 . 9mm |
| Full well capacity | 70000e- |
| Frame rate (full resolution) | 20fps@CameraLink ; 10fps@USB3.0 |
| Readout noise | HDR: 3.6e-(Median) |
| Shutter type | Rolling shutter |
| Exposure time | 10μs-300s |
| Bit depth | 16 bit |
| Dynamic Range | 86 dB |
| Cooling method | Forced air (Optional Liquid) |
| Dark current | 0.05e-/s/pix@-20℃（ambient at +20℃） |
| PRNU/DSNU | PRNU 0.2%, DSNU 0.5e- |
| Binning | 2×2/4×4 |
| Sub-array | Support |
| Anti-Dew | Support |
| External trigger mode | Hardware: Standard; Software |
| Trigger delay function | 0-10s(1μs steps) |
| Signal output ports | Exposure / Global / Readout / High level / Low level |
| External trigger routing | SMA |
| Digital interface | USB3.0 / CameraLink |
| SDK | Support |
| Lens mount | F-mount |
| Power supply | 12V/8A |
| Power consumption | 60W |
| Camera size | 95mm x 105mm x 153.9mm |
| Weight | 1800g |
| PC software | Mosaic 1.6/Samplepro/MAXIMDL/Labview/Matlab |
| Compatible system | Windows |
| Operating environment | 0-40℃, 10%-85% RH |
