A-2IPR Polarizing Microscope
| Parts | Specification | Order No. | A-22IPR | A-23IPR |
| MIC-200i Frame | MIC-200i | ● | ● | |
| Observation Tube | Binocular Tube, Interpupillary distance 52-75mm,
30°inclined. Diopter adjustment. |
MSP2 | ● | |
| Trinocular Tube, Interpupillary distance 52-75mm
30°inclined. Diopter adjustment. |
MTP2 | ● | ||
| Eyepieces | WF10X/20mm, High eye-point up to 21mm. | E1020PA | ●● | ●● |
| Plan Polarizing Reticule Eyepiece10X/20mm. | EP1020RA | ● | ● | |
| Objectives “Strain-free” Infinity Plan |
4X | WP-P4B | ● | ● |
| 10X | WP-P10B | ● | ● | |
| 40X(S) | WP-P40B | ● | ● | |
| 60X(S) | WP-P60B | ○ | ○ | |
| 50X(S) (for reflected light) | WM-P50A | ● | ● | |
| Polarizing
Condenser |
Swing-out Condenser N.A.1.25
(centering adjustable) |
JG50A | ● | ● |
| Stage | 360°Rotating Stage | ZT7 | ● | ● |
| Specimen Holder | ZT7-2000 | ●● | ●● | |
| Nosepiece | Quadruple Revolving Nosepiece | ZQP480 | ● | ● |
| Intermediate Tube | PY10 | ● | ● | |
| Reflected Light Illuminator | Illuminator
Filter(Blue, Yellow, Green, 50% cutting filter) Analyzer slider & Polarizer slider |
LS11 | ● | ● |
| Compensator | 1/4λ Retardation Plate | PBS137 | ● | ● |
| λ Tint Plate | PBS530 | ● | ● | |
| Quartz Wedge | PBSQ | ● | ● | |
| Kohler Illumination | With Field Diaphragm | KL3A | ● | ● |
| Electrical Parts | For 6V20W Halogen Lamp | DQ2 | ● | ● |
| 6V20W Osram Halogen Bulb | BZ-0022A | ● | ● | |
| Reflected Light Lamp house | DX10 | ● | ● | |
| Power Supply Unit For Reflected
Light Lamp house(12V/50W) |
DYX2 | ● | ● | |
| 12V50W Osram Halogen Bulb | BZ-0022D | ● | ● | |
| 250V/3.15A Φ5X20 Fuse | BZ-0023 | ●●● | ●●● | |
| C-Mount | 0.5X | SX2 | ● | |
| Filter | Blue (Φ38 ) | LA5-0011 | ● | ● |
| Immersion Oil | BZ-0027 | ● | ● | |
| Dust Cover | BZ2-0014 | ● | ● | |
| Allen Screw Driver | Φ2mm | BZ2-0018 | ● | ● |
| Φ1.5mm | BZ3-0018 | ●● | ●● | |
| Power Cord | BZ-0021 | ● | ● | |
| Package | ● | ● | ||
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological advances, we have reserved the right to make design modification and changes without notice.
