GM-26 20°/60°Gloss Meter
Widely used in Floor maintenance, Surface cleaning quality control, Stone and tile gloss measurement, Checking printed matter, Quality control of paint and ink, Polished metal surface, measurement
Features
* In accordance with international standard ASTMD523, ASTMD1455, ASTMC346, ASTMC584, ASTMD2457, DIN ENISO2813, DIN67530, ENISO7668, JISZ8741, MFT30064, TAPPIT480, GB9754, GB/T13891, GB7706 and GB8807. Its technical parameters conform with JJG696-2002.
* Accurate measurement, good repetitveness.
* Small in size, easy to carry.
* Auto calibration.
* Intelligent design, rapid measurement.
* Able to store 254 groups of measurements.
* Built-in lithium ion rechargeable battery.
* Backlight display, suitable for low light environment.
* Use USB/RS-232 data output to connect with PC.
* Provide Bluetooth data output choice.
Material And Angle Selection Recommended
* 20°: High gloss paint, printing ink, plastics, paper and other materials.
* 60°: Middle gloss paint, printing ink, plastics, ceramics, marble and other materials.
* 85°: Low gloss paint, camouflage coatings materials.
Specifications
| Display | 4 Digits Backlit LCD |
| Measuring Angle | 20º/60º |
| Range | 0.1GU~200 GU |
| Gloss Units | GU |
| Accuracy | ±1.0GU |
| Resoltuion | 0.1 |
| Repeatability | ±0.5GU |
| Measuring Area | 7mmx14mm（Ellipse） |
| Data Memorized | 254 Groups |
| Operating Conditions | Temp:0ºC ~40ºC Humidity:<85%RH |
| Power Supply | 3.7V Lithium Ion Rechargeable Battery |
| Dimensions | 140mmx45mmx75mm |
| Weight | 305g(Including Batteries) |
| Stabdard Accessories | Main Unit |
| Holder with Calibration Standard | |
| Optical Cleaning Cloth | |
| Carrying Case | |
| Operation Manual |
