Application
GTQ-5000A cutting machine is suitable for metal, electronic components, crystal, hard alloy, rock, ore, concrete, organic material, biological material(tooth, bone)and other materials. The equipment set high precision location and have large speed range. The cutting ability is strong and meanwhile the machine has strong cooling system. It can present feed speed and menu control with LCD. It is easy to control. Automatic cutting can reduce operator’s fatigue to ensure the consistency of the specimen. Therefore, it is an idea equipment for the industrial and enterprises and scientific research institute.
Technical Paramenters
| Model | GTQ-5000A |
| Feed speed | 0-1.50mm/s(adjust 0.01mm) |
| Spindle speed | 1950r/min |
| Max movement | Z 50mmY200mmX50mm |
| Cut-off wheel | Φ250×1.5×32mm |
| Input power | 1.8kw |
| Input voltage | 380V/50HZ |
| Dimension | 1000mm×1035mm×1200mm |
| Weight | 210kg |
