COATING THICKNESS GAUGE CM-8829H
Anticorrosion Coating Thickness Gauge
The F probes measure the thickness of non-magnetic materials on magnetic materials.
Features
* Measuring principle: magnetic induction (F).
* Two measurement mode: Single and Continuous（Notice：Continuous mode is convenient to measure the coating thickness of curved objects and tiny objects.）
* Metric/imperial system selectable.
* Manual or automatic shut down.
* Automatic memory of calibration value,and automatic recognize the substrate.
* Operation process have buzzing reminder,while no buzzing in continuous mode.
* Use USB/RS-232 data output to connect with PC.
* Provide Bluetooth data output choice.
| Principles | Applications | Examples |
| F Type Magnetic Induction (Iron Base) |
Measure the thickness of non-magnetic materials on magnetic materials | Galvanizing layer, lacquer layer, porcelain enamel layer, phosphide layer, copper tile, aluminium tile, some alloy tile, paper etc |
| Principle | F Magnetic Induction | √ |
| NF Type Eddy Current | √ | |
| Range | 0~12mm/0~480mil | |
| Resolution | 0.01mm/0.1mm | |
| Accuracy | ±1~3%or±0.2mm | |
| Min.Radius Workpiece | convex 20mm/concave 50mm | |
| Min.Measuring Area | 16mm | |
| Min.Sample Thickness | 0.3mm | |
| Metric/Imperial | Convertible | |
| Battery Indicator | Low Battery Indicator | |
| Automatic Power Off | √ | |
| Operating Conditions | Tempersture | 0~50ºC |
| Humidity | <80%RH | |
| Power Supply | 4×1.5V AAA(UM-4)Battery | |
| Dimensions | 126x65x27mm | |
| Weight(Not Including Batteries) | 210g | |
