HGM-2000 fog film gloss meter
Features
* is suitable for the maintenance of the flfloor, surface cleaning, such as surface gloss measurement.
* stones, the glossiness of ceramic tile measurement, spray paint and other surface gloss measurement.
* paint, ink, paint coating, such as wax membrane and car body paint surface gloss measurement
* the product design and production in line with international:ASTMD523， ASTMD1455，ASTMC346，ASTMC5 84，ASTMD2457， IS02813，DIN67530 ENIS07668， JISZ8741，MFT30064， PINPIT480， GB9754，GB/T13891 GB7706 and GB 8807 standard.Technical parameters meet the criteria of JJG 696-2002.
* plastic, paper and other surface gloss measurement.
* other non-metallic materials such as surface gloss measurement.
* can also show 200 Angle, Angle of 600 and 85. Angle measuring glossiness.
Principle
GLOSS (GLOSS) – measuring the percentage of the number of reflflected light. Reflflection fog shadow (HAZE) – due to bad coating pigment dispersion in the microstructure of emulsion appearance, will happen this optical effffect known as fog.Phenomenon: fog fifilm is high gloss surface characteristic of the phenomenon. Tiny grain of high gloss surface near the main produce low intensity in the direction of the reflflected light scattering light, but much of the incident light in the mirror reflflection, makes the surface seems to be high gloss and image quality, but the images have a milky mist. The lower the fog shadow reading, surface quality, the better.
Specifications
| Photometric units | GU |
| Measuring range | 0GU~2000 GU |
| Accuracy | ±1.5 (relative to the reference standard of JJG 696-2002) |
| Resolution | 0.1GU, repeatability :±0.5GU, error of indication: less than ±1.2GU |
| Projection Angle | 20°, 60° and85° |
| Fog shadow units | HU resolution± 0. 1 HU, repeatability ± 0. 2 HU,±1.5 HU reproducibility |
| The measurement area | 7mm x14mm (ellipse) |
| Numerical memory | 56 groups |
| Environment temperature | 0°C~40°C |
| Relative humidity | less than 85% |
| Battery | 3.7v lithium battery |
| Size | 140mm x45mmx75mm |
| Quantity | ±310 g(including battery) |
