J-Y1 Inverted Biological Microscope

Model J-Y1 series Inverted Biological Microscope with its excellent optical capability ,wide application, firm body frame and skillful figure design, meet the demands of biology, microbiology, histology immunology and etc.

This inverted biological microscope provides excellent functions .High resolution and contrast long working distance objectives provide high quality image. High contrast Phase contrast objectives make the figure and configuration of the cells more clear .The long working distance condenser can contain higher vessels or samples.

The stable & reliable “T” type base, streamline figure design, simple and convenient operating system makes your work easy and relax.

ENQUIRY!
分类： , , , 标签： ,
描述
Specification J-Y1 J-Y1T J-Y1A J-Y1AT
Viewing

head

 Compensation free Binocular Head .

Inclined at 4 5 ° ( 50mm -75mm )

 ●  / ●  /
Compensation Free Trinocular Head .

Inclined at 45 ° ( 50mm -75mm )

  / ●  / ●
Eyepiece WF10X/ 20mm ● ●
WF10X/ 22mm ● ●
WF10X/ 18mm with Cross

graduation of 0.1mm scale

 ○ ○ ○ ○
Objective Long

working

distance

plan

objective

 LWDPL4X/0.1W.D .25mm ● ●  /  /
LWDPL10X/0.25

phase contrast W.D .11mm
LWDPL20X/0.4

phase contrast W.D .6mm
LWDPL40X/0.6W.D. 3.8mm
Distance

infinity

plan

objective

 LWDPL4X/0.1W.D .29.4mm  /  / ● ●
LWDPL10X/0.25

phase contrast W.D .16mm
LWDPL20X/0.4

phase contrast W.D .10.5mm
LWDPL40X/0.6W.D .5.4mm
Long working

distance objective

 LWDPL10X ○ ○ ○ ○
LWDPL20X ● ● ● ●
Long working distance

phase contrast objective

 LWDPL40X ○ ○ ○ ○
Stage Double layers mechanical stage ● ● ● ●
Stage size: 242mmx 172mm
Central stage: Φ110mm
Moving range: 115mm × 75mm
Condenser N.A0.3Abbe condenser W.D .75mm ● ● ● ●
Focusing Coaxial coarse&fine focusing adjustment with rack and

pinion  mechanism Fine focusing scale Value 0.002mm

 ● ● ● ●
Phase contrast sliding plate Center of phase contrast

ring plate adjustable

 ● ● ● ●
Centering

telescope

 Centering telescope ● ● ● ●
Filter Blue, green, yellow and frosted glass ● ● ● ●
Light source Halogen bulb12V/30W ● ● ● ●
Adjustable brightness ● ● ● ●
Fluorescence attachment

B.G Wave band ,220V(110V)/100W Mercury lamp

 ○ ○ ○ ○
Photography

attachment

 Photograph connecting tube, adapter with MD or

PK mount ,4X photograph eyepiece

 ○ ○ ○ ○
Electron

Eyepiece

 1.3 or 3.0Mega pixels CMOS electronic  eyepiece ○ ○ ○ ○

Note: “●” in the table is standard attachment. “○” is optional accessories.

Design change: To keep pace with technological advances, we have reserved the right to make design modification and changes without notice.
