Model | MIA-402 | MIA-403 | MIA-408 | MIA-409 | |
Viewing
Body |
Square 45°Incline Monocular Body | ● | |||
Square 45°Incline Dual Viewing body | ● | ||||
30°Incline Binocular Body,
Interpupillary Adjustable Distance: 55mm~75mm |
● | ||||
30°Incline Trinocular Body (2/8 Light Spectrum),
Interpupillary Adjustable Distance: 55mm~75mm |
● | ||||
Eyepiece | WF10X (Viewing Field Diameter: ø18mm) | ||||
Objectives | Adjustable Parfocal Achromatic Objective
4×/NA 0.1,10×/NA 0.25,40×(s)/NA 0.65,100×(s, oil)/NA.1.25 |
||||
Fixed Stage | Size: 110mm×115mm,Moving Range: 60mm×30mm,Venire Division: 0.1mm | ||||
Nosepiece | Four Holes Plane Nosepiece | ||||
Condenser | Abbe Condenser: N.A.1.25, Elevating Range: 15mm | ||||
Focusing | Separate Coaxial Coarse/Fine Focusing System. Fine Focus Adjustment Range: >2mm.
Coarse Focus Adjustment Range:20mm(with Coarse Focusing Spare Limiter And Knob Slipping Protection Unit) |
||||
Illumination | Incandescent lamp 220V/20W Or 110V/20W | ● | ● | ● | ● |
Fluorescent Lamp 220V/5W Or 110V/5W | ○ | ○ | ○ | ○ | |
6V 20W Halogen Bulb, With Adjustable Brightness,
Free Voltage 100V-240V |
○ | ○ | ○ | ○ |
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological advances, we have reserved the right to make design modification and changes without notice.
