| Specification | |||||
| Model | MIA-A08 | MIA-A09 | MIA-AN08 | MIA-AN09 | |
| Total Mag | 40×-1600× | ||||
| Viewing Body | 30°Incline Binocular Body
Interpupillary Adjustable Distance: 55mm～75mm |
● | / | ● | / |
| 30°Incline Trinocular Body
Interpupillary Adjustable Distance: 55mm～75mm |
/ | ● | / | ● | |
| Eyepiece | WF10×(Viewing Field Diameter:ø18mm) | ||||
| Objectives | 4×/NA0.1,10×/NA0.25,40×(s)/NA0.65,100×(s,oil)/NA.1.25 | ||||
| Mechanical Stage | Size: 140mmx140mm, Moving Range: 70mmx50mm,
Vernier Division: 0.1mm |
||||
| Nosepiece | Nosepiece of four holes
revolving on ball(Outward) |
● | ● | / | / |
| Nosepiece of four holes
revolving on ball(Inflexed) |
/ | / | ● | ● | |
| Condenser | Abbe Condenser：N.A.1.25,Elevating Range:15mm | ||||
| Focusing | Coaxial Coarse/Fine Focusing Adjustment
Focusing Range:20mm,Division of Fine Focus Adjustment:0.002mm |
||||
| Illumination | 6V 20W Halogen Lamp With Adjustable Brightness
Free Voltage 100V-240V, Filter(blue、yellow、ground glass) |
||||
