GX2500 Industrial Camera
1, support 25 million / 40FPS
2, 10 GBit bandwidth
3, fiber 20 km transmission, a variety of frame rate selection
4, high-precision, large target surface
5, low temperature liter, low noise
6, support FFC/CES/HDR (black and white) function
7, support Windows 7 or more, Linux 64 Bit operating system
GX2500 model main application
Especially suitable for high-definition screen detection, AOI large-format detection, high-precision secondary measurement, appearance defect detection and so on.
| MODEL | GX2500 |
| Lens interface | Support M58 interface/C interface |
| Pixel | 25MP |
| Color mode | Color |
| Image size | 2.5×2.5μm |
| Optical size | diagonal line:17.6mm,about 1.1 inch |
| Shutter | Global Shutter |
| Frame rate | 40 FPS |
| Resolution | 5120 x 5120 |
| Any size ROI,minimum 32 x 32 | |
| SNR | 40db |
| Exposure time | 20us~5s |
| Gain range | 1x-12x |
| Full well capacity | 6.5ke |
| Dynamic range | 65db |
| Dark current | 1e/s/pixel@30℃ |
| Spectral response | 390nm~650nm |
| Image output format | Mono/Raw8、Raw16,24bit BMP format（BGR24） |
| Image bitwidth | 12bit |
| Multi-camera | support 4 cameras working at the same time |
| Trigger Mode | Hardware trigger/software trigger,Pulse width trigger |
GX2500M Industrial cameras
Pixels:25 MP
Frame Rate:40 fps
Coloration:Color/black and white
Shutter:Global Shutter
GX2500 Industrial Camera
1, support 25 million / 40FPS
2, 10 GBit bandwidth
3, fiber 20 km transmission, a variety of frame rate selection
4, high-precision, large target surface
5, low temperature liter, low noise
6, support FFC/CES/HDR (black and white) function
7, support Windows 7 or more, Linux 64 Bit operating system
GX2500 model main application
Especially suitable for high-definition screen detection, AOI large-format detection, high-precision secondary measurement, appearance defect detection and so on.
| MODEL | GX2500M |
| Lens interface | Support M58 interface/C interface |
| Pixel | 25MP |
| Color mode | MONO |
| Image size | 2.5×2.5μm |
| Optical size | diagonal line:17.6mm,about 1.1inch |
| Shutter | Global Shutter |
| Frame rate | 40 FPS |
| Resolution | 5120 x 5120 |
| 2500 x 2500（BIN2）only support MONO camera | |
| Any size ROI,minimum to 32 x 32 | |
| SNR | 40db |
| Exposure time | 20us~5s |
| Gain range | 1x-12x |
| Full well capacity | 6.5ke |
| Dynamic range | 65db |
| Dark current | 1e/s/pixel@30℃ |
| Spectral response | 390nm~650nm |
| Image output format | Mono/Raw8、Raw16,24bit BMP format（BGR24） |
| Image bitwidth | 12bit |
| Multi-camera | support 4 cameras working at the same time |
| Trigger Mode | Hardware trigger/software trigger,Pulse width trigger |
GX4300Industrial cameras
Pixels:43 MP
Frame Rate:17 fps
Coloration:
Shutter:Global Shutter
GX4300 Industrial Camera
1, 43 megapixel global exposure, 17FPS, APS-C
2, fiber 100 meters transmission, a variety of frame rate selection
3, 10 Gbit broadband
4, high precision, large target surface, low temperature rise, low noise
5, support FFC/CES/HDR (black and white) function
6, operating system: Windows 7 or more, Linux 64 Bit operating system
GX4300 model main application
Especially suitable for high-definition screen detection, AOI large-format detection, high-precision secondary meta-measurement, appearance defect detection, document scanning and so on.
| MODEL | GX4300 |
| Lens interface | Support M58 interface/F interface |
| Pixel | 43MP |
| Color mode | Color |
| Image size | 2.8 x 2.8μm（APS-C,about 1.68 inch,diagonal line:26.87mm） |
| Data interface | 10G fibre-optical interface |
| Shutter | Global Shutter |
| Frame rate | 17 FPS |
| Resolution | 7912 x 5432（42.98M） |
| Any size ROI,minimum to 32 x 32 | |
| Exposure time | 32us~5s |
| Trigger Mode | Hardware trigger/software trigger,Pulse width trigger |
| Power | 10-25V,about 7W |
| Single PC camera number | 1~4pcs camera |
| Transmission distance | Normal 300M,maximum to over 10kms |
| Spectral response | 390nm~650nm |
| Software interface | GenlCam、GigE Vision、Halcon/Labview plug-in |
| Camera size weight | 57 x 57 x 100mm,450g |
GX4300M Industrial cameras
Pixels:43 MP
Frame Rate:17 fps
Coloration:Color/black and white
Shutter:Global Shutter
GX4300M Industrial Camera
1, 43 megapixel global exposure, 17FPS, APS-C
2, fiber 100 meters transmission, a variety of frame rate selection
3, 10 Gbit broadband
4, high precision, large target surface, low temperature rise, low noise
5, support FFC/CES/HDR (black and white) function
6, operating system: Windows 7 or more, Linux 64 Bit operating system
GX4300M model main application
Especially suitable for high-definition screen detection, AOI large-format detection, high-precision secondary meta-measurement, appearance defect detection, document scanning and so on.
| MODEL | GX4300M |
| Lens interface | Support M58 interface/F interface |
| Pixel | 43MP |
| Color mode | MONO |
| Image size | 2.8 x 28μm（APS-C,about 1.68 inch,diagonal line:26.87mm） |
| Data interface | 10G fibre-optical interface |
| Shutter | Global Shutter |
| Frame rate | 17 FPS |
| Resolution | 7912 x 5432（42.98M）、3952 x 2716(BIN2) |
| Any size ROI,minimum to 32 x 32 | |
| Exposure time | 32us~5s |
| Trigger Mode | Hardware trigger/software trigger,Pulse width trigger |
| Power | 10-25V,about 7W |
| Single PC camera number | 1~4 pcs camera |
| Transmission distance | Normal 300M,maximum to over 10kms |
| Spectral response | 390nm~650nm |
| Software interface | GenlCam、GigE Vision、Halcon/Labview plug in |
| Camera size weight | 57 x 57 x 100mm,450g |
