MIC-610-3A ophthalmic surgery operation microscope is designed for ophthalmology surgical operation
Specification
| Eyepieces | magnification 12.5x, pupil distance adjustable range 55mm~75mm, diopter adjustment range +6D ~ -6D. Focus of second object lens 125mm |
| Binocular tube | high brightness 45°binocular tube |
| Magnification | manual 3-step changer, total magnification 6x,10x,16x; field of view Φ34mm,Φ20mm,Φ13mm |
| Coaxial assistant’s binocular tube | manual 3-step changer, total magnification 6x,10x,16x; field of view Φ34mm,Φ20mm,Φ13mm |
| Coaxial illumination | illumination diameter of light spot Φ50mm, illumination intensity 60000lux |
| Objectives | f200mm(175mm, 250mm etc ) |
| Focusing | motorized, range +/-25mm, speed 33s/whole distance |
| Maximum length of arm | 1100mm |
| New stand | Upgrade stand with new locking wheels |
| Foot switch | waterproof |
| Weight | 107kg |
| Packing | Gross weight(Kg): 105
Net weight(Kg):94 Three cartons(mm): 770x770x230 1180x530x217 594x460x230 |
