Treatment of dental pulp disease, Periodontal disease, restorative dentistry
MIC TECH professional surgery microscope, you see a fashionable, smooth lines, beautiful shape with a sense of modern design of high-end microscope, and modern consulting room perfect fit.
Under the fashionable appearance is full of excellent optical quality, you have upgraded to a higher level of clinical treatment,bringing you a higher quality, more efficient work experience.
MIC TECH operating microscope allows users to easily adjust the focal length without changing the sitting position or opening and moving the lens. Easier operation to prevent prolonged strain of cervical and lumbar spine.
MIC TECH high performance microscope is the perfect combination of excellent optical quality and comfortable handling.
MIC TECH high performance microscope is the perfect combination of excellent optical quality and comfortable handling.
The operating range of the MIC TECH professional-grade operating microscope zoom objective is 180-300mm, and the zoom objective lens has a zoom range of up to 180mm, covering almost all the operating range required for oral treatment. By adjusting the zoom knob,you can easily tighten the focus anywhere without changing the position of the microscope or your seat, making your job very easy.
German imported gas spring, the optimized force word structure enables you to move microscope any desired working Angle
conveniently and precisely.
A modular solution to fit your needs
MIC TECH microscope packs a high level of performance in is small package. Its compact design is tailored to optimize use of limited operating room space. From outpatient clinics to surgeries, MIC TECH offers flexibility and performance to serve every clinical requirement in the field of ENT, dental, gynecology and ophthalmology.
1080P full hd image quality, efficient image management during the operation. Integrate your digital workflow to facilitate case management and facilitate more intuitive patient communication.
Equipped with LED lighting system, to provide you with high-quality lighting, whether color resolution or color temperature are close to natural daylight, cost-effective, no maintenance. Less heat, less noise. You can also use the knob to control the brightness of the light and adjust it to an orange filter (to prevent curing of uv-curable resin materials and to extend the operating time).
Product Parameter
| Model | MIC-CD510-6B |
| Function | Dental |
| Electrical data | |
| Power socket | 220v(+10%/-15%) 50HZ/110V(+10%/-15%) 60HZ |
| Power consumption | 40VA |
| Safety class | class I |
| microscope | |
| Tube | 45 degree binocular tube |
| Magnification | manual 3-step changer, ratio 0.6，1.0，1.6 , total magnification 3.75x, 6.25x，12x ( F 250mm) |
| Stereo base | 22mm |
| Objectives | F=250mm (200mm,300mm,350mm,400mm or 180mm-300mm adjustable objectives for optional) |
| Objective focusing | 15mm |
| Eyepiece | 12.5x/ 10x |
| pupil distance | 55mm~75mm |
| Diopter adjustment | +6D ~ -6D |
| Field of view | 3 steps: Φ53mm，Φ32mm，Φ20mm |
| Light source | LED cold light with life time >80000 hours, brightness >60000 lux , CRI>90 |
| filter | OG530, Red free filter, small spot |
| Balance arm | 120° Balance arm |
| Automatic switching device | Built-in arm |
| Light intensity adjustment | Using a drive knob on the optics carrier |
| Stands | |
| Max extension range | 1193mm |
| Base | 610 × 610 mm |
| Transportation height | 1476 mm |
| Balancing range | Min 4 kg to max 7.7 kg load on the optics carrier |
| Brake system | Fine adjustable mechanical brakes for all rotation axes with detachable brake |
| System weight | 68 kg |
| Stand options | Ceiling mount,Wall mount,Floor plate,Floor stand |
| Accessories | |
| Knobs | Sterilizable |
| Video adapter | Mobile phone adapter, beam splitter, CCD adapter, CCD, SLR digital camera adapter,cam adapter |
| Ambient conditions | |
| Use | +10°C to +40°C |
| 30% to 75% relative humidity | |
| 500 mbar to 1060 mbar atmospheric pressure | |
| Storage | –30°C to +70°C |
| 10% to 100% relative humidity | |
| 500 mbar to 1060 mbar atmospheric pressure | |
| Limitations on use | |
| The MIC TECH surgical microscope may be used in enclosed rooms and on flat surfaces with max. 0.3° unevenness; or at stable walls or ceilings that fulfill MIC TECH Micro-system specifications (see installation manual) |
|
