MIC-CD610-3C ophthalmology microscope

Magnification:6X,10X,16X

Light source:12V/100W Halogen Lamp

Focusing:Motorized 50mm

Objective Lens:200(175,250,300,350,400)

Eyepiece:12.5x WF

Assistant tube:Coaxial assistant tube

Illumination:Build-in Illumination

Specification

Eyepieces magnification 12.5x, pupil distance adjustable range 55mm~75mm, diopter adjustment range +6D ~ -6D. Focus of second object lens 125mm
Binocular tube high brightness 45°binocular tube
Magnification manual 3-step changer, total magnification 6x,10x,16x; field of view Φ34mm,Φ20mm,Φ13mm
Coaxial assistant’s binocular tube manual 3-step changer, total magnification 6x,10x,16x; field of view Φ34mm,Φ20mm,Φ13mm
Coaxial illumination illumination diameter of light spot Φ50mm, illumination intensity 60000lux
Objectives f200mm(175mm, 250mm etc )
Focusing motorized, range +/-25mm, speed 33s/whole distance
Maximum length of arm 1100mm
New stand update stand with new locking wheels
Foot switch waterproof
Weight 107kg
其他信息
microscope function

Infinite, Compound, Dark filed, Polarizing, PH, fluorescent
