| Optical system | MIC TECH Infinite color corrected optical system |
| Head | Binocular head 30°inclined, 360° rotatable, rotatable, interpupillary distance 47-75mm |
| Trinocular head,30°inclined, 360° rotatable,
rotatable, interpupillary distance 47-75mm, beam splitting ratio R:T=8:2 |
|
| Eyepiece | Wide field plan eyepiece PL10X/18mm, diopter adjustable. |
| Wide field plan eyepiece PL10X/20mm, diopter adjustable. | |
| Objective | Infinite plan achromatic objective 4X、10X、20X、40X、60X、100X |
| Infinite plan positive phase contrast objective 10X、20X、40X、100X | |
| Nosepiece | Reversed quadruple or quintuple nosepiece |
| Focusing | Low position coaxial coarse and fine adjustment, Coarse adjustment range 25 mm
precision of fine adjustment:2um with locking system |
| Stage | 150mmX140mm double layer mechanical stage, double stage clips, moving range 76mm×50mm; precision:0.1mm（Triangle Guide） |
| 150mmX162mm double layer mechanical stage, double stage clips, moving range 76mm×50mm; precision:0.1mm （X single line rack-less moving, no gear parts, stage surface with resistant and corrosion resistant treatment | |
| Transmitting lighting system | MIC TECH fly-eyes-lens N.A.1.25 condenser (with slide type PH, dark field interface) condenser center preset-ted, up-down function is optional. Auto wide voltage 100-240v, single 3W LED high brightness bulb(cold-warm color to be chosen), light temperature 4750K-5500K, warm color temperature 2850K-3250K |
| C mount | 0.35X/0.5X/0.65X/1X C-mount, focus adjustable |
| Other optional | Polarizing kits, filters, PH slides, dark field slides. |
