The MIC-M76 series continuous zoom stereo microscope provides high-quality optical systems and durable and reliable operating mechanisms. The brand new design showcases the best resolution and authentic color images, meeting the high-precision requirements of modern biomedical, scientific research, modern electronic industry online detection, and other technological industries.

Performance characteristics:

High quality optical components coated with special film layers create high-quality optical images Form a flat image plane and good contrast in a large field of view, especially in the peripheral field of view where the image quality is brighter and clearer

Adopting a continuous zoom objective lens of 0.7X-6.0X (8.6:1), using a WF10X eyepiece, standard magnification of 7X-60X (optional auxiliary objective lens, magnification can reach 3.5X-200X)

The effective standard working distance reaches 120mm, and with the optional auxiliary objective lens, the working distance will be extended to 120mm-172mm, creating sufficient space for use The observation head is tilted 45 degrees and the binocular vision is adjustable, ensuring that users with different visual acuity can obtain clear and satisfactory images

Ergonomic structural design, optimal eye point height, and fatigue free long-term use

Horizontal (axial) dual sided setting of variable magnification hand wheel, easy and comfortable operation, high repeatability accuracy of variable magnification

Equipped with multiple accessories to expand application areas

Parameter:
