MIC-LHCCD Series Linear USB2.0 CCD Camera
Back to products
Next product
MIC-PHA HDMI CMOS camera SD card

MIC-PAD860 microscope pad 11.6 inches

MIC PAD860 adopts Panasonic IPS LCD panel(Super TFT) to guarantee the wide view angle and high contrast. Together with HDMI camera, MIC PAD860 could make the imaging & display solution simple, flexible and intuitive. Outstanding performance of MIC PAD860 helps the HDMI camera reach fast frame rate and excellent color.

MIC PAD860 basic characteristic is as follows

HDMI monitor;

Panasonic IPS LCD panel;

True 1080P;

High contrast ratio up to 1000:1;

LED backlight with 50000 hours long life time;

11.6 inch active area;

ENQUIRY!
分类： , , , 标签： , , , , , , , , , , , , , , , , , , , ,
描述

Data sheet

Model number Active Area(Inch) Video Format Resolution Contrast Color(Million) View Angle
MIC-PAD860 11.6 HDMI 1080P 1000:1 16.7 IPS Full View

MIC-PAD860 Data sheet

Basic Performance
LCD Panel Panasonic IPS LCD Screen(Super TFT)
Input Video Format HDMI
Native Resolution 1920×1080
Display Type 16:9Ratio11.6Inch Active Matrix Super TFT LCD
Typical Contrast Ratio 1000:1
Colors 16.7Million
Viewing Angle(L/R/U/D) IPS Full View
Active Display Area 258mm(W)×145mm(H)
Pixel Pitch 0.134(W)X0.134(H)mm
Brightness 350cd/sq.m;400cdsq.m /Optional
Backlight LED Back light,50000hours
Outline Parameter
Color Black
Dimension 281(L)*179(H)*15.6(W) mm
Weight 400g



Operating Environment
Operating Temperature -15Degree~55Degree
Humidity Non Condensing Operating:10%-90%,Storage:5%-90%
Synchronization Range 30-80KHzHorizontal,55-75HzVertical
Power Supply AC110V-220V /DC12V(1A)
Power Consumption Max12W
其他信息
microscope function

Infinite, Compound, Dark filed, Polarizing, PH, fluorescent
用户评价 (0)

评价

目前还没有评价

成为第一个“MIC-PAD860 microscope pad 11.6 inches” 的评价者

您的邮箱地址不会被公开。 必填项已用 * 标注

Shipping & Delivery

EX-WORK price

ALL PRICE MIC TECH QUOTED IS EX-WORK PRICE.

OTHER PRICE INCLUDING SHIPPING WILL BE QUOTED UPON REQUEST.

FAS CPT CIP FCA FOB CFR CIF DPT DIP DDP

  • ALL TERMS OF SHIPPING IS NEGOTIABLE WITH MIC TECH
  • ALL SHIPPING METHODS IS JUST ON YOUR REQUEST
  • YOUR SATISFACTION IS OUR GOAL
