- From 1.4 Mp to 8.0Mp without difference image, some models have color/black and white are optional.
•The white balance, a key, easy to obtain high fidelity color reproduction image.
• Image detail are outstanding, high-definition, high dynamic range and low noise.
• S1 series of CCD chip optional cooling to ambient temperature 30 degrees.
• A variety of photo formats: BMP, JPEG, PNG, TIFF.
• With professional imaging analysis software
• Support DirectShow and Twain, can provide the SDK
| Model | Sensor | Resolution | Colour |
| PL TC01C | 2/3″SONY IC285 | 1.4 | color |
| PL TC01M | 2/3″SONY IC285 | 1.4 | Monochrome |
| Model | PL TC01C/M |
| Sensor Model | 2/3 INCH SONY IC285 |
| Sensor Dimension | 6.45μm×6. 45μm |
| Resolution | 1360×1024,2×2bin |
| Scan Method | Progressive Scan |
| Sensibility | 1.24V |
| Frame Rate | 26fps@1360×1024 40fps@680×520 |
| Shutter | electronic shutter |
| SNR | 74db |
| Spectral Response | 400nm～1000nm |
| Inter Face | USB3.0 |
| Power | DC 5V±5% |
| Current | ≈400mA |
| White Balance | White Balance |
| Auto Exposure Control | 26us-30min |
| Lens Mount | CS interface optional C |
| Busy Indicator | LED |
| Working temperature | 0℃ ～ 40℃ |
| Working Humidity | 10-90% |
Software:MIC TECH professional image analysis software with modular designing,including image previewing,capturing,analyzing,processing,sharing function.It gives users the latest image processing experiences.The software function:image capturing,time lapse,measuring,data exporting image mosaic,depth of field overlaying,text instruction inserting,etc.
