MIC-SM3200 Surgical Microscope
Magnification: Motorized zoom system, Zoom magnification factor 0.4x -2.4x (1:6)
Magnification range: 1.8x-20x with 12.5x eyepieces
Field of View: 11.6mm-124mm with 12.5x eyepieces
Tube: 0°-180° inclinable binocular tube with PD knobs or MagPlus 1.5 0°-180° inclinable binocular tube with PD knobs (optional), boosts magnification by 50%
Eyepieces:
12.5x widefield eyepieces, suitable for eyeglass wearers
12.5x widefield eyepieces, suitable for eyeglass wearers with reticle (optional)
10x widefield eyepieces, suitable for eyeglass wearers (optional)
Objective/Focus: Motorized VarioDist Objective Lens, Variable working distance 200-450mm
BriPlus Illumination System:
Integrated true color LED illumination CT5000K /CRI92>80000 Lux at working distance 250mm
30% auto-increased intensity at maximum magnific
Yellow and Green Filter station, >105000 Lux
Illumination spot between 90mm-73mm at working distance 250mm
Twin Switchable LED illumination (Optional under the preset
without FluoDet Fluorescence Module selected)
Controls:
FreeMov Electromagnetic System
MFH multi-functional handles: below buttons to lock/unlock three brakes, joysticks for Motorized Zoom +/-, Motorized focus +/-, four buttons for taking photo/video, lighting +/-
Multi-function Foot pedal (optional): Motorized Zoom +/-, Motorized focus +/-, taking photo/video, lighting +/-
Smart Mon LCD display: displaying current working distance, zoom factor, magnification, measurement factor, LED brightness
Fluorescence (optional): FluoDet Fluorescence Module
Laser Filter (optional):
Interchangeable laser filters: Argon:488~514nm, Diode: 660nm,Diode: 800~830nm,
Diode 980nm & NdYag 1064nm,Co2 10600nm & Erbium 2780-2940nm
Integrated 2D/3D Video System (optional):
Integrated 1080p full HD video streaming HDMI to desktop devices and mobiles
with Windows PC / Android / iOS via MIC TECH App, transferred via wireless WIFI or wired RJ45
Micro3D-II, 2×1 / 1.8″ Sony CMOS, 1x2D HDMI output and 1x3D HDMI output
