| Items | Specification | O-M3 | |
|
Eyepiece |
WF10X/20mm (High eyepoint) | ● | |
| WF10X/20mm(H, adjustable Focus,Reticule 0.1mm) | ● | ||
|
Long Working Distance Infinity Plan Objective (no cover glass) |
LPL 5×/0.13 | W.D=16.04mm | ● |
| LPL 10×/0.25 | W.D=18.48mm | ● | |
| LPL 20×/0.4 | W.D=8.35mm | ○ | |
| LPL 50×/0.7 | W.D=1.95mm | ● | |
| LPL 80×/0.8 | W.D=0.85mm | ○ | |
| LMPlan FL 100×／0.85(Dry) | W.D=3.00m | ○ | |
| Swiveling Seidentopf
Binocular Head |
Inclined 30°,Rotatable 360°,
Interpupilary Distance: 48 -75mm |
● | |
| Swiveling Seidentopf
Trinocular Head |
Inclined 30°,Rotatable 360°,
Interpupilary Distance: 48 -75mm Light Distribution 80:20 |
○ | |
| Nosepiece | Quadplex | ● | |
| Mechanical Stage | Stage Size: 200×140mm, Travel : 76mm×52mm
Coaxial Coarse and Fine Focusing Knobs |
● | |
| Reflection Illumination | 5WLED Warm lamp (Input voltage：100V～240V) | ● | |
| Filter | Five-hole filter unit(blue, green, amber, grey, empty) | ● | |
| Polarizing Attachment | Analyzer/ Polarizer | ○ | |
|
C-mount |
1× | ○ | |
| 0.5X （Focus Adjustable） | ○ | ||
|
Image System |
USB2.0 3MP digital camera for trinocular head(measurement software) | ○ | |
| USB2.0 5MP digital camera for trinocular head(measurement software) | ○ | ||
| USB3.0 12MP digital camera for trinocular head(measurement software) | ○ | ||
| 9.7” LCD touch screen tablet camera for trinocular head (measurement software) | ○ | ||
Note: “●”In Table Is Standard outfits, “○” Is Optional Accessories.
MIT200 Packing Size: 570mm×275mm×450mm Gross Weight: 10.5 kgs Net Weight: 8 kgs
