SL-5868ILEQ Impulse Integrating Sound Level Meter
The Impulse Integrating Sound Level Meter is a universal sound level meter, an integrated sound level meter. It can also measure Accumulated percentile sound level.
Features
* Its performance is in accordance with GB/T 3785-2010 standard level 2 And IEC 61672:2013 Class 2 sound level meter requirements. It also meets the JJG 188-2017 standard.
* With the function of integration and statistics, 800 groups of single measurement and 6 days of regular measurement can be achieved. The stored data can be read and printed. The collected data can be checked when the regular measurement ispaused.
* The three time weighting F, S, and I can be selected.
* The digital detection technology is used to replacesome traditional sound level meters, the stability andreliability are greatly improved.
* Large screen display is adopted, with clear and intuitive display. With dynamic scale display.
* Optional Bluetooth printer for data printing.
* Use USB data output to connect with PC.
* Provide Bluetooth data output choice.
Specifications
| Microphone | Φ12.7mm (1/2′) test condenser microphone |
| Frequency weighting | A, C, and Lin(Linear) |
| Range | 25dB~130dB (A) |
| Range control | Manual, three gears, linear range > 60dB |
| Testing Range | 30dB~90dB (dynamic scale display 10dB~100dB) |
| 50dB~110dB (dynamic scale display 30dB~120dB) | |
| 70dB~130dB (dynamic scale display 50dB~140dB) | |
| Accuracy | In accordance with IEC61672 standard, class 2 |
| Time Weighting | Fast (F), Slow (S), Impulse (I) |
| Display | Large screen dynamic LCD, instantaneous sound level, with analogammeter display. |
| The output interface | AC signal output |
| USB data cable output | |
| Calibration | Use class 1 sound level calibrator |
| Power Supply | 4×1.5V AAA Size (UM-4) Battery |
| External Power | 6V |
| Weight | 185g (Not Including Batteries) |
| Dimensions | 227mmx63mmx26 mm |
| Operating Condition | Temperature: -10°C~50°C |
| Standard Accessories | Main Unit |
| Windscreen | |
| Carrying Case (B04) | |
| Manual | |
| Optional Accessories | CD |
| Data Cable | |
| Bluetooth Data Adapter | |
| Bluetooth printer | |
| Printer power adapter | |
| External power supply (6V) |
