| Eyepieces | WF10X (Φ22mm)， high eye point |
| Objective | Stereo zoom objective |
| Zoom range 0.7～6.3(zoom ratio 1:9) | |
| Work distance110mm | |
| Total magnification | System standard ratio 7～63 |
| Field range | Φ33.8～Φ3.49 |
| Vertical effective movement | 220mm |
| Base size | 310mmX280mm |
| Light source | Reflected illuminating 3W High brightness LED |
| Transmitted illuminating 5W High brightness LED |
Optional accessories
| Name | Sort/Technique parameter |
| Eyepiece | Wide field eyepiece WF15X(Φ15mm) |
| Wide field eyepiece WF20X(Φ12mm) | |
| Wide field eyepiece WF25X(Φ9mm) | |
| Dividing eyepiece WF10X （Φ22mm） | |
| Illuminator | LED EPI-fluorescence illuminator or annular fluorescence illuminator |
| Additional objective | 0.5X Working distance:165mm/1.5X /2X |
| CCD adapter | 0.4X/0.5X/1X/0.5X with dividing |
| Camera | DV-130 / 300 / 500 / 1000 With USB output |
| Digital camera adapter | CANON（EF）/NIKON（F） |
