Ultrasonic Thickness Meter TM-1240
Used for measuring thickness and corrosion of pressure vessels, chemical equipment, boilers, oil storage tanks, etc industries of petroleum, shipbuilding, power station and machine manufacturing.
Features
* Using the latest high performance and low power consumption microprocessor technology.
* Automatic memory material code and sound velocity value, convenient to use.
* Use USB/RS-232 data output to connect with PC.
* Provide Bluetooth data output choice.
Material Selection
Code | Material |
CD01 | Steel |
CD02 | Cast Iron |
CD03 | Aluminum |
CD04 | Red Copper |
CD05 | Brass |
CD06 | Zinc |
CD07 | Quartz Glass |
CD08 | Polyethylene |
CD09 | PVC |
CD10 | Gray Cast Iron |
CD11 | Nodular Cast Iron |
XXXX | Sound Velocity |
Specifications
Display | LCD |
Operating Principle | Ultrasonic |
Measuring Range | 0.75mm~400mm(45#steel)(Depend on Probe) |
Resolution | 0.1mm/0.01mm/0.001inch |
Accuracy | ±(0.5%n+0.1mm) |
Lower Limit of Pipes | Φ15mmx2.0mm Φ20mmx3.0 mm
Determined By Transducer |
Sound Velocity | 1000m/s~9999 m/s |
Operating Conditions | Temperature:0ºC ~40ºC Humidity:<85%RH |
Power Supply | 4×1.5V AAA(UM-4)Battery |
Dimensions | 140mmx72mmx34mm |
Weight | 185g(Not Including Batteries) |
Standard Accessories | Main Unit |
Standard Probe | |
Coupling Agent | |
Carrying Case(B04) | |
Operation Manual | |
Optional Accessories | Other Special-purpose Probe |
RS-232C Data Cable with Software | |
Bluetooth Data Adapter with Software |
