| Eyepiece | Wide field WF10X，(field number Ф18mm) | |||||
| Objective | type | magnification | N.A. | Work
distance (mm) |
Cover glass
thick (mm) |
note |
| Semi-plan
achromatic Objective (standard) |
4X | 0.10 | 23.13 | 0.17 | ||
| 10X | 0.25 | 4.09 | 0.17 | |||
| 40X | 0.65 | 0.60 | 0.17 | |||
| 100X | 1.25 | 0.38 | 0.17 | oil | ||
| Plan achromatic
Objective (option) |
4X | 0.10 | 17.90 | 0.17 | ||
| 5X | 0.12 | 18.30 | 0.17 | |||
| 10X | 0.25 | 8.80 | 0.17 | |||
| 20X | 0.40 | 8.60 | 0.17 | |||
| 25X | 0.40 | 0.65 | 0.17 | |||
| 40X | 0.65 | 0.56 | 0.17 | |||
| 60X | 0.85 | 0.25 | 0.17 | |||
| 100X | 1.25 | 0.33 | 0.17 | oil | ||
| Eyepieces tube | Binocular( inclinaion 30°)，inerpupillary distance：48~75mm. (Trincular can be choose) | |||||
| Focus system | Coaxial coarse/fine focus with tension adjustable and up stop,minimum
division of fine focusing:2.0μm.，moving range:0～20mm |
|||||
| Nosepiece | Quadruple backward ball bearing inner locating | |||||
| Stage | Double layer mechanical stage (size:125mmX135mm,moving range:35mmX75mm) | |||||
| Condenser system | Abbe condenser, with aperture diaphragm , rack & pinion adjustment .
(dark field condenser or phase contrast unit can be choose) |
|||||
| Light source | 3W high brightness white LED brightness adjustable.(6V20W halogen lamp can be choose) | |||||
| Power supple | AC 100～240V（suitable for LED brightness）
AC 110V/220V （ suitable for 6V20W halogen lamp ） |
|||||
