Specification | XSZ-
N3A |
XSZ-
N3H |
XSZ-
N3T |
|
Viewing
Head |
Monocular Inclined at 45°,360°Rotatble | ● | ||
Compensation Free Binocular Head, Inclined at 30°(55mm-75mm) | ● | |||
Compensation Free Trinocular Head, Inclined at 30°(55mm-75mm) | ● | |||
Eyepiece | WF10×/18mm | ● | ● | ● |
Objective | Achromatic 4×、10×、40×(s)、100×(s)Oil | ● | ● | ● |
Nosepiece | Backward Quadruple Nosepiece | ● | ● | ● |
Stage | Double layer mechanical stage | ● | ● | ● |
Stage Sixe:140mm×132mm | ||||
Moving Range:70mm×30mm | ||||
Condenser | N.A.1.25 Abbe condenser with iris diaphragm and filter | ● | ● | ● |
Focusing | Coaxial coarse & fine focusing adjustment fine focusing scale value 0.002mm | ● | ● | ● |
Light
Source |
Halogen bulb 6V20W or 6V15W, AC 220V/110V | ● | ● | ● |
Adjustable light intensity | ||||
Optional
Accessory |
Eyepiece:WF16×、WF20×、P16× | |||
Objective:20×、60(s) | ||||
Semi-plan Objective:4×、10×、20×、40×(s)、60×(s)、100×(s)oil | ||||
Plan Objective:4×、10×、20×、40×(s)、60×(s)、100×(s)oil | ||||
Reflective Mirror, Demonstration (Teaching) Head Dark field and Phase contrast device | ||||
1.3Mega、2.0Mega、3.0Mega、5.0Mega pixels CMOS Digital camera eyepiece | ||||
Photography attachment and CCD Adapter 0.5×、0.57×、0.75× | ||||
Compensation Free Binocular & Trinocular Head (48mm-75mm) | ||||
LED illumination |
