■ All optical components are through special processing and coated with special film, formed a high-quality flat and good contrast optical images in the wide field. Especially in the peripheral visual field, it is more bright and clear.
■ Zoom objective lens 0.67X~4.5X (6.7:1), standard magnification 6.7X~45X. Use optional auxiliary lens, the magnification can be 2X~225X.
■ The standard working distance is 100mm, use optional auxiliary lens, the working distance can extend to 26mm~287mm
■ Viewing head 45°inclined, best eye-point height, correspond with ergonomic design, feel less fatigue when long time use.
■ Adopt diopter adjustment eyepiece, ensure the different vision of users to get a clear image.
■ The zoom hand wheel (axial) bilateral settings, easy operation, high precision zoom repeat.
■ Built-in wide-range voltage 110V~240V, top & bottom LED illuminator, uniform lighting and separate control.
■ Brightness is adjusted separately, it can provide long time and same color temperature lighting in whichever light intensity.
■ Stable light intensity, low voltage, low consumption, low heating value and long lifetime
Specifications
| Eyepiece | Wide field high eye-point diopter adjustment eyepiece WF10X/22mm（can mount micrometer） |
| Wide field high eye-point diopter adjustment eyepiece WF15X/16mm（can mount micrometer） | |
| Wide field high eye-point diopter adjustment eyepiece WF20X/12mm（can mount micrometer） | |
| SZN71：Binocular head, 45° inclined, 360°rotatable, zoom objective 0.67X-4.5X,
working distance 100mm. interpupillary range 54~76mm, both two tube diopter adjustment(±5), built-in interlocking device, fixed eyepiece tube |
|
| Viewing Head | SZN745：Binocular head, 45° inclined, 360°rotatable, zoom objective 0.67X-4.5X,
working distance 100mm. interpupillary range 54~76mm, both two tube diopter adjustment(±5), built-in interlocking device, fixed eyepiece tube |
| SZN745TR：Trinocular head, 45° inclined, 360°rotatable, zoom objective 0.67X-4.5X,
working distance 100mm. interpupillary range 54~76mm, both two tube diopter adjustment(±5), built-in interlocking device, fixed eyepiece tube |
|
| SZN760：Binocular head, 60° inclined, 360°rotatable, zoom objective 0.67X-4.5X,
working distance 100mm. interpupillary range 54~76mm, both two tube diopter adjustment(±5), built-in interlocking device, fixed eyepiece tube |
|
| Trinocular head, 45° inclined, 360°rotatable, zoom objective 0.8X-5X, working distance 100mm. | |
| Trinocular head, 45° inclined, 360°rotatable, zoom objective 1X-6.7X, working distance 100mm. | |
| Auxiliary Lens | 0.3X/ 287mm |
| 0.4X/217mm | |
| 0.5X/177mm | |
| 0.75X/117mm | |
| 1.5X/47mm | |
| 2X/26mm | |
| Focus | ST70A1 focus arm, two focusing knobs are with tension adjustable, adjust range 50mm |
| SZA2 industry bound focus arm 1 (industry exclusive use) | |
| SZA3 industry bound focus arm 2 (industry exclusive use) | |
| Stand | B4 pillar type sector plain stand |
| B5 pillar type large plain stand (no hole) | |
| B6 arm type large sector plain stand | |
| BL1 arm type stand, LED top & bottom illuminator, brightness adjustment | |
| BL3 pillar type large sector LED stand (brightness adjustment) (used with ST70A1). | |
| SZSTL1 single arm universal stand | |
| SZSTL2 double arm universal stand | |
| SZ-B1 transmitted light base, be used with SZ-ST1 | |
| Other light
source |
Ring light/LED/Fiber |
| Photo device | Photo tube（with PK mount），4X photo eyepiece |
| TV device | 0.35X/0.5X/1.0X C-mount adapter |
| Others | Precision measurement platform, dark field condenser, jewelry clip |
