SPECIFICATION
Model | Eyepiece | Objective | Working stage | Illumination |
XTX-6A | WF10× | Rotated 1×-2× 1×-3× 2×-4× |
φ60 White/black | Natural illumination |
XTX-6C | WF10× | φ95 Frosted glass | Incident illumination & transmitted illumination | |
XTX-6A-W | WF10× | φ60 White/black | Natural illumination | |
XTX-6C-W | WF10× | φ95 Frosted glass | Incident illumination & transmitted illumination |
OPTICAL DATA
Objective | Eyepiece | WD | |||||||
5× | 10× | 15× | 20× | ||||||
M | FOV | M | FOV | M | FOV | M | FOV | ||
1× | 5× | 20.0mm | 10× | 20.0mm | 15× | 15.0mm | 20× | 10.0mm | 76mm |
2× | 10× | 10.0mm | 20× | 10.0mm | 30× | 7.5mm | 40× | 6.5mm | |
1× | 5× | 20.0mm | 10× | 20.0mm | 15× | 15.0mm | 20× | 10.0mm | 76mm |
3× | 15× | 7.0mm | 30× | 6.7mm | 45× | 5.0mm | 60× | 4.3mm | |
2× | 10× | 10.0mm | 20× | 10.0mm | 30× | 7.5mm | 4× | 6.5mm | 76mm |
4× | 20× | 5.0mm | 40× | 5.0mm | 60× | 3.7mm | 80× | 3.2mm |
