Main parameters | Total magnification | 100X (standard configure) | ||||
Mechanical tube length | ∞ | |||||
Conjugate distance of objective | ∞ | |||||
Eyepiece | Wide-field
plan eyepiece |
WF 10X | field of view
number Ф18mm |
Eyepiece
interface Ф23.2mm |
Parfocal
Distance 10mm |
|
Trinocular | Observation angle of 30° with photography port
spectro rate 8:2(eyepiece:photography) |
|||||
Strain-free
plan achromatic objective |
Magnification | Numerical
aperture |
Working distance
(mm) |
Thickness of
cover glass (mm) |
Remarks | |
10X | 0.25 | 20.2 | – | |||
Analyzer | Insert type,can be switch freely,the direction of polarization has preset, no use for adjust | |||||
Polarizer | Insert type,can be switch freely,360°rotatable | |||||
DIC Slider | DIC slider matching 5X/10X/20X objective,horizontal adjustable | |||||
X-Y Stage | double layer mechanism stage, size:180 X 145mm,moving range:35X 30 mm(X-Y) | |||||
Vertical
availability distance |
Focus system available distance 133mm,
observational specimen maximal thickness up to 130mm. |
|||||
focus system | Coaxial coarse/fine focus system, minimum division of fine focusing: 2μm | |||||
Illumination | Coaxial illumination using high brightness white LED. Brightness adjustable | |||||
Main power
supply |
AC:85V~265V 50/60Hz,fuse specification:250V 3.0A | |||||
Accessory
(optional) |
Objective | 20X strain-free plan achromatic objective
NA:0.40,working distance:8.0mm |
||||
Digital camera | 130、300、500、1000mega pixels,with image analysis software. |
