Specification
ITEM | Technical Specifications |
Total Magnification | 50X-500X |
Head | 30° Binocular Compensation Body,Interpupillary Adjustable Distance: 55mm~75mm |
30° Trinocular compensation Body,Interpupillary Adjustable Distance: 55mm~75mm | |
Eyepiece: | WF10×/:20mm |
Metallurgical Plan Objetive (No Cover glass) | 4×/NA0.10.WD=28.5. 10×/NA0.25.WD=28.5、
20×/NA0.40.WD=5.05.L40×(S)/NA0.66.WD=2.46 |
Auxiliary Objective | 1.25X |
Nosepiece | Four Holes Nosepiece of Ball Bearing |
Mechanical Stage | 190mmX145mm,Range:75mmX50mm,Vernier:0.1mm |
Focusing | the up-stop and Coaxial Coarse /Fine focusing system,Division of Fine Focus Adjustment:0.002mm |
Filter | Yellow、Green、Blue, |
C mount | 0.5X |
Bulb: | 6V/30W Hallogen, Brightness Adjustment, A.C.220V(50Hz) |
