MIC-M2 inverted metallurgical microscope
UCIS Infinity Independent Achromatic Optical System
WF10x plan eyepieces, 20mm field of view, high eye point up to 21mm, WF10X18mm Reticule Eyepiece
Seidentopf binocular viewing head, inclined45º
52-75mm interpupillary distance settings ±5 Diopter adjustment
Quintuple nosepiece inward facing with positive click stops
Infinity long work distance plan Achromatic 10x, 20x, 40x and 80x objectives
Right hand controls, low position, Mechanical Stage, Size: 180mm×155mm, Movement Range: 80mmX50mm
Coaxial coarse and fine focus mechanism with markings on fine focus knobs. Fine focus sensitivity 0.001mm
12volt 50 watt halogen illumination, Reflection Koehler illuminator with iris diaphragm and centerable filed diaphragm
MIC-M3 inverted metallurgical microscope
● New research and new development
● Combination with bight field, dark field, polarizing observation etc. Widely used in metal, mineral, electronic field
● Dark field objective，Make observation in dark & bright field.
● Oversize view field eyepiece, view field up to 22mm for comfortable
● Trinocular head with dual transform.
● Light distribution (both): 100: 0（100% for eyepiece）
80:20（80% for trinocular head and 20% for eyepiece）
MIC-M4 inverted metallurgical microscope
● New research and new development
● Combination with bight field, dark field, polarizing observation etc. Widely used in metal, mineral, electronic field
● Dark field objective，Make observation in dark & bright field.
● Oversize view field eyepiece, view field up to 22mm for comfortable
● Trinocular head with dual transform.
● Light distribution (both): 100: 0（100% for eyepiece）
80:20（80% for trinocular head and 20% for eyepiece）
MIC-M5 inverted metallurgical microscope
UCIS Infinity Independent Achromatic Optical System
WF10x plan eyepieces, 20mm field of view, high eye point up to 21mm, WF10X20mm Reticule Eyepiece
Seidentopf binocular viewing head, inclined45º
52-75mm interpupillary distance settings ±5 Diopter adjustment
Quintuple nosepiece inward facing with positive click stops
Infinity long work distance plan Achromatic 10x, 20x, 40x and 80x objectives
Right hand controls, low position, Mechanical Stage, Size: 350mm×208mm, Movement Range: 50mmX50mm
Coaxial coarse and fine focus mechanism with markings on fine focus knobs. Fine focus sensitivity 0.001mm
12volt 50 watt halogen illumination, Reflection Koehler illuminator with iris diaphragm and centerable filed diaphragm
XJP-8A inverted DIC fluorescent metallurgical microscope
MIC TECH’S new advanced XJP-8A inverted bright & dark field metallurgical microscope is designed with infinite optical system,wide field eyepiece and long working distance bright & dark field infinite plan objectives and polarization device.As a large scientific research level metallurgical microscope,it meets the demand of all kinds of physio-chemical analysis and inspection.It can be equipped with microscopic photography & video and image analysis system.The instrument can be used in metallurgic examination and analysis and the research work of surface coating,crack and so on.
