A-2ip polarizing microscope

★Infinite optical system with perfect optical characteristic

★Integrated frame design with stable operation quality

★Single polarizing observation, orthogonal polarization and conoscopic observation is available.

★Analysis and test for all kinds of mineral sample and other samples under polarizing.

Identification of various biological and non biological materials, such as starch property identification, drug composition identification, fiber, liquid crystal, DNA crystal, etc.

Medical analysis: such as stone, uric acid crystal detection, arthritis, etc.

Geological and mineral analysis.

ENQUIRY!
分类： , , 标签： , ,
描述
Parts Specification Order No. A-22IP A-23IP
A-2i Frame A-2i ● ●
Observation Tube Binocular Tube, Interpupillary distance 52-75mm, 30°inclined. Diopter adjustment. MSP2 ●
Trinocular Tube, Interpupillary distance 52-75mm, 30°inclined. Diopter adjustment. MTP2 ●
Eyepieces WF10X/20mm, High eye-point up to 21mm. E1020PA ●● ●●
WF10X/22mm, High eye-point up to 21mm. E1022PC ○○ ○○
Plan Eyepieces, 16X/14mm. E1614PA ○○ ○○
Plan Polarizing Reticule Eyepiece10X/20mm. EP1020RA ● ●
Objectives

“Strain-free”

Infinity

Ach.

 4X WP-X4B ● ●
10X WP-X10B ● ●
40X(S) WP-X40B ● ●
60X(S) WP-X60B ○ ○
100X(S)/(Oil) WP-X100B ● ●
Objectives

Infinity

Plan Ach.

 2X WB-P2A ○ ○
4X WB-P4C ○ ○
10X WB-P10C ○ ○
20X(S) WB-P20C ○ ○
40X(S) WB-P40C ○ ○
60X(S) WB-P60C ○ ○
100X(S)/(Oil) WB-P100C ○ ○
Condenser Swing-out Condenser N.A.1.25 JG50A ● ●
Stage 360°Rotating Stage ZT7 ● ●
Specimen Holder ZT7-2000 ●● ●●
Attachable Mechanical Stage ZT7-3000 ○ ○
Nosepiece Quadruple Revolving Nosepiece ZQP480 ● ●
Intermediate Tube PY10 ● ●
Compensator 1/4λ Retardation Plate PBS137 ● ●
λ Tint Plate PBS530 ● ●
Quartz Wedge PBSQ ● ●
Kohler Illumination(With Field Diaphragm) KL3A ● ●
Electrical

Parts

 For 6V20W Halogen Lamp DQ2 ● ●
For 6V30W Halogen DQ2A ○ ○
For 3W LED (With Rechargeable Battery) DQLC2 ○ ○
For 3W LED DQL2B ○ ○
6V20W Halogen Bulb BZ-0022 ●●● ●●●
6V20W Osram Halogen Bulb BZ-0022A ● ●
6V30W Halogen Bulb BZ-0022B ○○○ ○○○
6V30W Osram Halogen Bulb BZ-0022C ○ ○
3W LED Bulb DQL2-1000 ○ ○
2200mAh LED Rechargeable Battery UDCH-5300 ○ ○
250V/3.15A Φ5X20 Fuse BZ-0023 ●●● ●●●
C-Mount 0.5X SX2 ●
1X SX3 ○
0.25X SX4 ○
Filter Blue (Φ38 ) LA5-0011 ● ●
Green (Φ38) LU5-0011 ○ ○
Yellow (Φ38) LH5-0011 ○ ○
Frosted Glass (Φ38) LB5-0011 ○ ○
Other Immersion Oil BZ-0027 ● ●
Dust Cover BZ2-0014 ● ●
Φ2mm Allen Screw Driver BZ2-0018 ● ●
Φ1.5mm Allen Screw Driver BZ3-0018 ●● ●●
Power Cord BZ-0021 ● ●

Note: “●” in the table is standard attachment. “○” is optional accessories.

Design change: To keep pace with technological advances, we have reserved the right to make design modification and changes without notice.
