Abbe Refractometer

2W 2WAJ Abbe Refractometer

Use

Measurement of transparent and translucent liquids or solids and the average of the refractive index ND dispersion NF-NC. Equipment can also be received with thermostat, to determination of the temperature 0 ℃ -70 ℃ for the refractive index of ND, and measured the volume of sugar solution concentration in percentage of sugar content.     Therefore, this instrument is the oil industry, oil industry, pharmaceutical industry, building paint industry, food industry, daily-use chemical industry, sugar industry and geological survey of the factory and so on, teaching and scientific research units indispensable one of the commonly used equipment.

Specification

 Automatic Digital Abbe Refractometer 2WE

Use：

Automatic Digital Refractometer Abbe is the latest development of our concept of a new condenser Abbe Refractometer automatically, it does not need manual alignment and reading, just to test the liquid droplets in the table, close the lid, click the Test button, all the work automatically, the required data are displayed on the screen, including: the date, temperature, refractive index, concentration, and amended in accordance with the current temperature of the refractive index and concentration, and with built-printers, print test data can be archived.      Automatic Digital Refractometer Abbe eliminated a lot of manual operation and calculation record. Many errors can be avoided and the calculation error, test, record data true and reliable.

Technical parameters：

1．Measurement range：refractive index   1.3000－1.7000         Concentration   0－95%

2．Measurement precision：refractive index   ±0.0003         Concentration  ±0.5%

3．Min. reading：refractive index   0.0001                 Concentration   0.1%

4．Print method：high-speed thermal  TP211F  Printing density：paper width 58mm   8 points/ mm  384dots/line

5．Power：220V  50Hz

6．Instrument net weight：3kg

7．Instrument size：350×210×180mm

National Patent Product: Patent No.: ZL 2007 2 0667892.2
